Danfoss VLT AutomationDrive FC 302 Operating Instructions Manual page 65

How to Install
FC 300
Bussmann
Power
[kW]
Type JFHR2 2)
0.25-0.37 FWX-5
0.55-1.1 FWX-10
1.5 FWX-15
2.2 FWX-20
3.0 FWX-25
3.7 FWX-30
5.5 FWX-50
7.5 FWX-60
11 FWX-80
15-18.5 FWX-125
22 FWX-150
30 FWX-200
37 FWX-250
Table 3.32 200-240 V, Frame Sizes A, B, and C
1) KTS-fuses from Bussmann may substitute KTN for 240 V frequency converters.
2) FWH-fuses from Bussmann may substitute FWX for 240 V frequency converters.
3) A6KR fuses from FERRAZ SHAWMUT may substitute A2KR for 240 V frequency converters.
4) A50X fuses from FERRAZ SHAWMUT may substitute A25X for 240 V frequency converters.
FC 300
Bussmann
Power
[kW] Type RK1
0.37-1.1 KTS-R-6
1.5-2.2 KTS-R-10
3 KTS-R-15
4 KTS-R-20
5.5 KTS-R-25
7.5 KTS-R-30
11 KTS-R-40
15 KTS-R-50
18 KTS-R-60
22 KTS-R-80
30 KTS-R-100
37 KTS-R-125
45 KTS-R-150
55 KTS-R-200
75 KTS-R-250
Table 3.33 380-500 V, Frame Sizes A, B, and C
®
VLT Automation Drive FC 300 Operating Instructions
Recommended max. fuse
Littel fuse
JFHR2
-
-
-
-
-
-
-
-
-
-
L25S-150
L25S-200
L25S-250
Recommended max. fuse
Bussmann Bussmann
Type J Type T
JKS-6 JJS-6
JKS-10 JJS-10
JKS-15 JJS-15
JKS-20 JJS-20
JKS-25 JJS-25
JKS-30 JJS-30
JKS-40 JJS-40
JKS-50 JJS-50
JKS-60 JJS-60
JKS-80 JJS-80
JKS-100 JJS-100
JKS-125 JJS-125
JKS-150 JJS-150
JKS-200 JJS-200
JKS-250 JJS-250
MG33U402 - Rev. 2013-12-16
Ferraz-
Shawmut
JFHR2 4)
-
-
-
-
-
-
-
-
-
-
A25X-150
A25X-200
A25X-250
Bussmann Bussmann
Type CC Type CC
FNQ-R-6 KTK-R-6
FNQ-R-10 KTK-R-10
FNQ-R-15 KTK-R-15
FNQ-R-20 KTK-R-20
FNQ-R-25 KTK-R-25
FNQ-R-30 KTK-R-30
- -
- -
- -
- -
- -
- -
- -
- -
- -
Ferraz-
Shawmut
J
HSJ-6
3
HSJ-10
HSJ-15
HSJ-20
HSJ-25
HSJ-30
HSJ-50
HSJ-60
HSJ-80
HSJ-125
HSJ-150
HSJ-200
HSJ-250
Bussmann
Type CC
LP-CC-6
LP-CC-10
LP-CC-15
LP-CC-20
LP-CC-25
LP-CC-30
-
-
-
-
-
-
-
-
-
63
3
