Warnings and Alarms
ALARM 31, Motor phase V missing
Motor phase V between the frequency converter and the
motor is missing.
Remove power from the frequency converter and check
motor phase V.
ALARM 32, Motor phase W missing
Motor phase W between the frequency converter and the
motor is missing.
Remove power from the frequency converter and check
motor phase W.
ALARM 33, Inrush fault
Too many power-ups have occurred within a short time
period. Let the unit cool to operating temperature.
WARNING/ALARM 34, communication fault
The fieldbus on the communication option card is not
working.
WARNING/ALARM 36, Mains failure
This warning/alarm is only active if the supply voltage to
the frequency converter is lost and 14-10 Mains Failure is
NOT set to [0] No Function.
Troubleshooting
•
Check the fuses to the frequency converter and
mains power supply to the unit
ALARM 38, Internal fault
When an internal fault occurs, a code number defined in
the Table 6.4 is displayed.
Troubleshooting
•
Cycle power
•
Check that the option is properly installed
•
Check for loose or missing wiring
Contact the Danfoss supplier or service department if
required. Note the code number for further trouble-
shooting directions.
No. Text
0 Serial port cannot be initialised. Contact the
Danfoss supplier or Danfoss Service Department.
256-258 Power EEPROM data is defective or too old.
512 Control board EEPROM data is defective or too
old.
513 Communication time out reading EEPROM data.
514 Communication time out reading EEPROM data.
515 Application oriented control cannot recognize the
EEPROM data.
516 Cannot write to the EEPROM because a write
command is on progress.
517 Write command is under time out.
518 Failure in the EEPROM.
519 Missing or invalid barcode data in EEPROM.
783 Parameter value outside of min/max limits.
1024-1279 A centelegram that has to be sent couldn't be
sent.
®
VLT Automation Drive FC 300 Operating Instructions
No.
1281
1282
1283
1284
1299
1300
1301
1302
1315
1316
1317
1318
1379
1380
1381
1382
1536
1792
2049
2064-2072
2080-2088
2096-2104
2304
2305
2314
2315
2316
2324
2325
2326
2327
2330
2561
2562
MG33U402 - Rev. 2013-12-16
Text
Digital signal processor flash timeout.
Power micro software version mismatch.
Power EEPROM data version mismatch.
Cannot read digital signal processor software
version.
Option SW in slot A is too old.
Option SW in slot B is too old.
Option SW in slot C0 is too old.
Option SW in slot C1 is too old.
Option SW in slot A is not supported (not
allowed).
Option SW in slot B is not supported (not
allowed).
Option SW in slot C0 is not supported (not
allowed).
Option SW in slot C1 is not supported (not
allowed).
Option A did not respond when calculating
platform version.
Option B did not respond when calculating
platform version.
Option C0 did not respond when calculating
platform version.
Option C1 did not respond when calculating
platform version.
An exception in the application oriented control is
registered. Debug information written in LCP.
DSP watchdog is active. Debugging of power part
data, motor oriented control data not transferred
correctly.
Power data restarted.
H081x: option in slot x has restarted.
H082x: option in slot x has issued a powerup-wait.
H983x: option in slot x has issued a legal
powerup-wait.
Could not read any data from power EEPROM.
Missing SW version from power unit.
Missing power unit data from power unit.
Missing SW version from power unit.
Missint lo_statepage from power unit.
Power card configuration is determined to be
incorrect at power up.
A power card has stopped communicating while
main power is applied.
Power card configuration is determined to be
incorrect after the delay for power cards to
register.
Too many power card locations have been
registered as present.
Power size information between the power cards
does not match.
No communication from DSP to ATACD.
No communication from ATACD to DSP (state
running).
