How to Install
Power Bussmann
[kW] Type RK1
1.1 KTS-R-5
1.5-2.2 KTS-R-10
3 KTS-R15
4 KTS-R20
5.5 KTS-R-25
7.5 KTS-R-30
11 KTS-R-35
15 KTS-R-45
18 KTS-R-50
22 KTS-R-60
30 KTS-R-80
37 KTS-R-100
45 KTS-R-125
55 KTS-R-150
75 KTS-R-175
Table 3.38 525-690V, Frame Sizes A, B, and C
FC 302 Bussmann
Max.
[kW] E52273
prefuse
Power RK1/JDDZ
11 30 A KTS-R-30
15-18.5 45 A KTS-R-45
22 60 A KTS-R-60
30 80 A KTS-R-80
37 90 A KTS-R-90
45 100 A KTS-R-100
55 125 A KTS-R-125
75 150 A KTS-R-150
* UL compliance only 525-600V
Table 3.39 525-690 V*, Frame Sizes B and C
Supplementary fuses
Frame size
D, E and F
Table 3.40 SMPS Fuse
Size/Type
P90K-P250, 380-500 V
P37K-P400, 525-690 V
P315-P800, 380-500 V
P500-P1M2, 525-690 V
Table 3.41 Fan Fuses
®
VLT Automation Drive FC 300 Operating Instructions
Recommended max. fuse
Bussmann Bussmann
Type J Type T
JKS-5 JJS-6
JKS-10 JJS-10
JKS-15 JJS-15
JKS-20 JJS-20
JKS-25 JJS-25
JKS-30 JJS-30
JKS-35 JJS-35
JKS-45 JJS-45
JKS-50 JJS-50
JKS-60 JJS-60
JKS-80 JJS-80
JKS-100 JJS-100
JKS-125 JJS-125
JKS-150 JJS-150
JKS-175 JJS-175
Recommended max. fuse
Bussmann Bussmann
E4273 E4273
J/JDDZ T/JDDZ RK1/JDDZ
JKS-30 JKJS-30 5017906-030
JKS-45 JJS-45 5014006-050
JKS-60 JJS-60 5014006-063
JKS-80 JJS-80 5014006-080
JKS-90 JJS-90 5014006-100
JKS-100 JJS-100 5014006-100
JKS-125 JJS-125 2028220-125
JKS-150 JJS-150 2028220-150
Bussmann PN*
KTK-4
Bussmann PN*
KTK-4
KTK-4
MG33U402 - Rev. 2013-12-16
Bussmann Bussmann
Type CC Type CC
FNQ-R-5
FNQ-R-10 KTK-R-10
FNQ-R-15 KTK-R-15
FNQ-R-20 KTK-R-20
FNQ-R-25 KTK-R-25
FNQ-R-30 KTK-R-30
-
-
-
-
-
-
-
-
-
SIBA LittelFuse
E180276 E81895
RK1/JDDZ
KLS-R-030
KLS-R-045
KLS-R-060
KLS-R-075
KLS-R-090
KLS-R-100
KLS-150
KLS-175
LittelFuse
KLK-15
KLK-15
Bussmann
Type CC
KTK-R-5 LP-CC-5
LP-CC-10
LP-CC-15
LP-CC-20
LP-CC-25
LP-CC-30
- -
- -
- -
- -
- -
- -
- -
- -
- -
Ferraz- Ferraz-
Shawmut Shawmut
E163267/E2137 E2137
RK1/JDDZ J/HSJ
A6K-30-R HST-30
A6K-45-R HST-45
A6K-60-R HST-60
A6K-80-R HST-80
A6K-90-R HST-90
A6K-100-R HST-100
A6K-125-R HST-125
A6K-150-R HST-150
Rating
4 A, 600 V
Rating
4 A, 600 V
4 A, 600 V
15A, 600 V
15A, 600 V
3 3
