How to Install
2.5-4.0 A Fuse
3 3
4.0-6.3 A Fuse
6.3 - 10 A Fuse
10 - 16 A Fuse
Table 3.42 Manual Motor Controller Fuses
Frame size
F
Table 3.43 30 A Fuse Protected Terminal Fuse
Frame size
F
Table 3.44 Control Transformer Fuse
Frame size
F
Table 3.45 NAMUR Fuse
Frame size
F
Table 3.46 Safety Relay Coil Fuse with PILZ Relay
68
®
VLT Automation Drive FC 300 Operating Instructions
Size/Type Bussmann PN*
P450-P800, 380-500 V LPJ-6 SP or SPI
P630-P1M2, 525-690 V LPJ-10 SP or SPI
P450-P800, 380-500 V LPJ-10 SP or SPI
P630-P1M2, 525-690 V LPJ-15 SP or SPI
P450- LPJ-15 SP or SPI
P800600HP-1200HP,
380-500 V
P630-P1M2, 525-690 V LPJ-20 SP or SPI
P450-P800, 380-500 V LPJ-25 SP or SPI
P630-P1M2, 525-690 V LPJ-20 SP or SPI
Bussmann PN*
LPJ-30 SP or SPI
Bussmann PN*
LPJ-6 SP or SPI
Bussmann PN*
Bussmann PN*
LP-CC-6
MG33U402 - Rev. 2013-12-16
Rating
6 A, 600V
10 A, 600V
10 A, 600V
15 A, 600V
15 A, 600V
20 A, 600V
25 A, 600V
20 A, 600V
Rating
30 A, 600 V
Rating
6 A, 600 V
GMC-800MA
Rating
6 A, 600 V
Alternative Fuses
Any listed Class J Dual
Element, Time Delay, 6 A
Any listed Class J Dual
Element, Time Delay, 10 A
Any listed Class J Dual
Element, Time Delay, 10 A
Any listed Class J Dual
Element, Time Delay, 15 A
Any listed Class J Dual
Element, Time Delay, 15 A
Any listed Class J Dual
Element, Time Delay, 20A
Any listed Class J Dual
Element, Time Delay, 25 A
Any listed Class J Dual
Element, Time Delay, 20 A
Alternative Fuses
Any listed Class J Dual Element,
Time Delay, 30 A
Alternative Fuses
Any listed Class J Dual Element, Time
Delay, 6 A
Rating
800 mA, 250 V
Alternative Fuses
Any listed Class CC, 6 A
