Warnings and Alarms
No. Description
57 AMA time-out
58 AMA internal fault
59 Current limit
60 External Interlock
61 Feedback Error
62 Output Frequency at Maximum Limit
63 Mechanical Brake Low
64 Voltage Limit
65 Control Board Over-temperature
66 Heat sink Temperature Low
67 Option Configuration has Changed
68 Safe Stop
69 Pwr. Card Temp
70 Illegal FC configuration
71 PTC 1 Safe Stop
72 Dangerous failure
73 Safe Stop Auto Restart
74 PTC Thermistor
75 Illegal Profile Sel.
76 Power Unit Setup
77 Reduced power mode
78 Tracking Error
79 Illegal PS config
80 Drive Initialized to Default Value
81 CSIV corrupt
82 CSIV parameter error
83 Illegal Option Combination
84 No Safety Option
88 Option Detection
89 Mechanical Brake Sliding
90 Feedback Monitor
91 Analog input 54 wrong settings
163 ATEX ETR cur.lim.warning
164 ATEX ETR cur.lim.alarm
165 ATEX ETR freq.lim.warning
166 ATEX ETR freq.lim.alarm
250 New spare parts
251 New Type Code
Table 6.1 Alarm/Warning Code List
(X) Dependent on parameter
1) Can not be Auto reset via 14-20 Reset Mode
A trip is the action when an alarm has appeared. The trip
coasts the motor and can be reset by pressing [Reset] or
®
VLT Automation Drive FC 300 Operating Instructions
Warning Alarm/Trip
X
X X
X
X X
(X) (X)
X
(X)
X
X X
X
X
(X) 1)
(X)
X
(X) (X)
X
X
X
(X) (X)
X
X
X
X
X
X
(X) (X)
X
X
X
X
X
make a reset by a digital input (parameter group 5-1*
Digital Inputs [1]). The origin event that caused an alarm
cannot damage the frequency converter or cause
dangerous conditions. A trip lock is an action when an
alarm occurs, which may damage the frequency converter
MG33U402 - Rev. 2013-12-16
Alarm/Trip Lock Parameter
Reference
4-30 Motor Feedback
Loss Function
2-20 Release Brake
Current
X
5-19 Terminal 37 Safe
Stop
X
X
5-19 Terminal 37 Safe
Stop
X
14-59 Actual Number of
Inverter Units
4-34 Tracking Error
Function
X
X
X
17-61 Feedback Signal
Monitoring
X S202
X
X
