Table 210. callCleared Codes from 3.6.4/V.58-1994(Continued)
Note: callCleared indicates that the DCE has gone on-hook and that the previously existing network con-
nection has been cleared. These values are hexadecimal, converted from decimal in V.58. Refer to
Table 10 in the Microsoft specification.
Value Description
5A FrameReject.
5B NoErrorControlEstablished.
5C ProtocolViolation.
5D n400exceeded.
5E NegotiationFailed.
5F DisconnectFrameReceived.
60 SabmeFrameReceived.
64 LossOfSynchronization.

S-Registers

The current setting of each S-register may be displayed by the command (S<register number>?). There
are two forms for this command.
Table 211. S<register number> Extended Syntax
Syntax
S<register number>?
S<register number>=<value>*
* Some registers are read only and are not affected by the S<register number>=<value> command.
Table 212 summarizes the S-registers used by USRobotics controller-based modems.
Table 212. S-Register Summary
Register
S0 Auto-answer ring number.
S1 Ring counter.
S2 AT escape character (user defined).
S3 Command-line termination character (user
defined).
S4 Response-formatting character.
S5 Command-line editing character.
S6 Wait before dialing.
S7 Connection completion time-out.
S8 Pause time for comma (,) modifier.
S9 DTMF off=time duration
S10 Automatic disconnect delay.
S11 DTMF tone duration.
S12 Escape guard time.
S14 General bit-mapped options status.
S18 Dial-pulse interdigit period.
S21 V.24/general bit-mapped options status.
Error control.
Data compression.
Displays register contents.
Sets the contents of the register to <value>.
Description
56K USB Modem
Notes Implemented
-
-
-
-
-
-
Function
Range Unit
0-255 Rings
0-255 Rings
0-255 ASCII
0-127 ASCII
0-127 ASCII
0-8 ASCII
2-255 s
1-255 s
0-65 s
50-200 ms
1-255 100 ms
50-150 ms
0-255 20 ms
- -
0-255 5 ms
- -
Command Reference - 95
User Guide
-
X
-
X
-
-
-
-
Default
0
0
43
13
10
8
2
50
2
95
20
95
50
8
48
