Table 204. #UD Last Call Status Report Format(Continued)
Note: Refer to Table 1 in the Microsoft specification.
Key Value(s) Required
34 4 digits 0—FA00
35 4 digits 0—FA00
36— —
3F
40 See
Table 207
on page 93.
41 3 digits
42 2 digits
43 2 digits
44 See
Table 208
on page 93.
45 4 digits
46— —
4F
50 1 digit
51 1 digit
52 8 digits
FFFFFFFF
53 8 digits
FFFFFFFF
54 8 digits 0—FFFF
55 8 digits 0—FFFF
56 8 digits
FFFFFFFF
57 8 digits
FFFFFFFF
58 8 digits 0—FFFF
59 8 digits 0—FFFF
5A— —
5F
60 See Note 10*
Table 209
on page 93.
* Refers to notes or tables in the Microsoft specification.
Final transmit carrier rate.
Final receive carrier rate.
— Reserved.
0—2 Protocol negotiation result (see note 7 *).
0—400 Error control frame size.
0—FF Error control link time-outs.
Error control link NAKs.
0—FF
0—1 Compression negotiation result (see note 7 *).
0—200 Compression dictionary size (see note 7 *).
— Reserved.
0—2 Transmit flow control.
• 0 = off.
• 1 = DC1/DC3.
• 2 = V.24 ckt 106/133.
0—2 Receive flow control.
• 0 = off.
• 1 = DC1/DC3.
• 2 = V.24 ckt 106/133.
Transmit characters sent from DTE (see note 8 *).
0—
0— Receive characters sent to DTE (see note 8 *).
Transmit characters lost (data overrun errors from
DTE) (see note 9 *).
Receive characters lost (data overrun errors from
DTE) (see note 9 *).
0— Transmit frame count, if error control protocol running
(see note 9 *).
Receive frame count, if error control protocol running
0—
(see note 9 *).
Transmit frame error count, if error control protocol
running (see note 9 *).
Receive frame error count, if error control protocol
running (see note 9 *).
— Reserved.
Termination cause.
Definition
56K USB Modem
User Guide
Implemented
X
X
—
X
—
X
—
X
—
—
X
X
X
X
X
X
X
X
X
X
—
X
Command Reference - 91
