Table 204. #UD Last Call Status Report Format(Continued)
Note: Refer to Table 1 in the Microsoft specification.
Key Value(s) Required
61 2 digits
62— —
7F
80-FF —
* Refers to notes or tables in the Microsoft specification.
Table 205. Call Setup Result Codes
Note: Refer to Table 2 in the Microsoft specification.
Code
0 No previous call (modem log has been cleared since any previous call).
1 No dial tone detected.
2 Reorder signal detected. Network busy.
3 Busy signal detected.
4 No recognized signal detected.
5 Voice detected.
6 Text telephone signal detected (see V.18).
7 Data answering signal detected (e.g., V.25 ANS, V.8ANSam).
8 Data calling signal detected (e.g., V.25 CT, V.8 CI).
9 FAX answering signal detected (e.g., T.30 CED, DIS).
A FAX calling signal detected (e.g., T.30 CNG).
B V.8bis signal detected.
C—F Reserved.
Table 206. gstnModulationSchemeActive from 3.7.2/V.58
Note: Refer to Table 6 in the Microsoft specification.
Value
(hexadecimal)
0 V.17.
1 V.21.
2 V.22.
3 V.22bis.
4 V.23 constant carrier (1200/75).
5 V.23 switched carrier (half duplex).
6 V.26bis.
7 V.26ter.
8 V.27ter.
9 V.29 HD.
A V.32.
B V.32bis.
C V.34.
D V.34 HD.
E V.pcm (asymmetric).
0—FF Call waiting event count.
— Reserved for future versions of the specification.
Reserved for manufacturer proprietary keys.
—
Definition
Description
Definition
Implemented
—
—
—
—
—
—
—
—
—
—
X
—
X
—
—
56K USB Modem
User Guide
Implemented
X
—
—
Implemented
X
X
—
X
X
—
—
X
—
—
—
—
—
Command Reference - 92
