7. Input or selection of combustion plants

To call up plant data already recorded or to create a new file, the following
possibilities are available:
Create new (is automatically selected
by first use of a MM card): To create a
new file, a numerical number should be
assigned.
Select „Create new" and confirm with
<Enter>. Input a random number (max.
16 figures) using the keyboard:
- use the cursor keys <Up/Down/Right/Left> to select
the figure (selected figure outlined by a black background)
- press <Enter> to accept the figure (press <F2> to delete
the last figure if needed)
- repeat this procedure until the desired number is complete.
Example: "25.11.2008"
Tip: We suggest a date-related input to easily find the data
record later on via the search function.
After confirming with <F1> it is possible to enter a text via the keyboard
(max. 6 lines with 20 characters each) which is printed out and can be
used for data processing purposes. Proceed as follows:
- select text line 1 using the cursor keys <Up/Down> and
confirm with <Enter>
- select with <F3> the keyboard mode (4 keyboard modes
are available)
- select with the cursor keys <Up/Down/Right/Left> the desired
character (selected character outlined by a black background)
- press <Enter> to accept the character (press <F2> to delete the
last character)
- repeat this procedure until the desired text is complete.
Page 10
Selection upon:
Search word
Record number
Create new
Quit with: ESC
ecom-EN2
