EN2 Manual Addendum
Setup Data Processing Shortcut to F1 Hotkey
1. Turn on analyzer
2. Go to Adjustments -> Internal -> F1 Hotkey
3. Press right arrow to select Data processing and press ENTER
4. The F1 Hotkey is now set to Data Processing -> Press ESC twice to return to Main Menu
How to Log Data on a Memory Card
1. Insert memory card into slot located above the printer
2. From Gas Analysis, press F1 hotkey to go to Data Processing
3. Select Datalogger -> Save to MMC -> Input desired logging interval in seconds and press
ENTER
4. Select Datalogger -> Prompt "Start dl? Are you sure?" -> Press F1/yes
5. Analyzer is now in Datalogging mode. The blinking disk in the top right corner indicates that
datalogging is activated. Press ESC to return Gas Analysis. You are now viewing real-time
results while the analyzer is logging data.
6. Once the test is complete, press F1 hotkey to go to Data Processing
7. Select Datalogger -> Datalogger (again) -> Prompt "Finish dl? Are you sure?" -> Press
F1/yes
8. You are done! Press down on the memory card to release from the slot and insert memory
card into a card reader on a computer to view your results in Microsoft Excel.
NOTE: The file will be saved as "J2KDL-xx.csv"
Quick Print
1. Enter Gas Analysis mode
2. Press F2 to print real-time readings
Print from memory:
1. While in Gas Analysis mode, press 7/Save to save snapshot to memory (disk icon
will appear in the memory box)
2. Press 6/Printer key to print data snapshot from memory
3. Press 7/Save to clear memory (disk icon will clear from memory box)
I. Data Logging onto Memory Card
II. How to Print
