8.6. Soot...Oil trace
The sub-menu "Soot...Oil trace" enables
the input of measured results for boiler
temperature, soot dots and oil trace.
Select the desired line on the display and
activate the input with <Enter>. The input
for boiler temperature and soot
measurements 1-3 can be made one after
the other with help of the instrument
keyboard. Press <Enter> to store the value
in the data record of the measurement.
The result of the oil trace check will be documented as follows:
- Place cursor on line "Oil trace"
- Consign the result with <Enter>
("No", "Yes" or "- - - ")
Once all inputs have been entered, press <ESC> to exit the menu. The
measurement is now complete.
ecom-EN2
Let the probe cool down before fixing it back
in the fixation in the case cover!
Soot..Oil trace
Boiler temp. :
1.Soot meas. :
2.Soot meas. :
3.Soot meas. :
Oil trace :
↑↓
Select :
Soot..Oil trace
Boiler temp. :
1.Soot meas. :
2.Soot meas. :
3.Soot meas. :
Oil trace :
↑↓
Select :
66°C
-.-
-.-
-.-
----
↵ ↵ ↵ ↵ ↵
66°C
1.0
0.5
1.5
NO
↵ ↵ ↵ ↵ ↵
Page 19
