7. Run the hydraulic hose up the back of the Swim Unit Housing so that the PVC
hydraulic hose protective channel will cover the hose. Firmly secure but do NOT
over tighten the eight stainless screws per channel. Repeat for the second
hose.
8. Once both protective channels are attached, pull the two hydraulic hoses tight and
secure them to the top of the Swim Unit Housing using the green hose clamps
provided. To accomplish this, unscrew the green hose clamps, insert the hoses, and
re-screw the clamps snugly into the top of the Swim Unit Housing. Feed the bond
wire (from Step 6) to the back of the Swim Unit Housing along one of the hydraulic
hoses.
9. Attach the acrylic hanging bracket to the back of the Swim Unit Housing with four of
the 3/4" stainless steel screws. NOTE: Do not over-tighten. Leave the two top
screw holes unused.
