Diagram #2: Wider Straight Tube Layout - Endless Pools FASTLANE Owner's Manual

Page 5 of 32
3. Connect bottom tubes (Part F) to struts (Part G) one at a time to make the four sides
of the pool. Connect corner tubes (Part E) to the open ends of both struts to finish
each of the four corners.
4. Connect the top tubes (Parts B and C) together. NOTE: The shorter tube (Part C)
is always the last tube on the right when facing the pool wall. (Refer to

Diagram #2: Wider Straight Tube Layout.)

Standard (9' x 13') Fastlane Pool
D
FLPoolOMWMWQSver1.4.a
DIAGRAM #2: WIDER STRAIGHT TUBE LAYOUT
C
B
Longer (9' x 17') Fastlane Pool
D
2/3/09
C
B
