LifeSize Multipoint unit. The 10/100BaseT port accepts an
RJ-45 connector.
Turn on the power to the LifeSize Multipoint unit.
2
You must also configure an IP address for the video processing module. The IP
address of the video processing module must be different than the IP address
configured for the LifeSize Multipoint unit.
Initial monitoring and administration of the video processing module are
performed from a remote PC using a terminal emulation application, such as
HyperTerminal. To make the serial connection, connect a PC terminal to the
lower serial port on the front panel of the LifeSize Multipoint unit as described
in
Connecting to a PC
target configuration service. You can use the serial configuration utility to:
Configure default network port values.
Modify the configuration software password.
Modify the LifeSize Multipoint unit IP address.
Modify advanced configuration settings such as the web server port
and LAN port, and to restore the factory configuration.
You access the video processing module Main configuration menu in the same
way as you access the LifeSize Multipoint unit network configuration Main
menu as described in
Procedure
The video processing module Main configuration menu appears as follows:
Main menu
N: Configure default network port values
P: Change the configuration software password
S: Configure network security level
M: Change MCU ip address
A: Advanced configuration menu
Q: Quit
Select:
Video Processing Module Initial Configuration
on page 14. The serial configuration utility runs as a
on page 15.
Setting Up Your LifeSize Multipoint
19
