SYSTEM

The system menu specifies analog component (HD) output, analog composite output, phase adjustment of audio output, system
frequency, phase of SD REF input of HD output, and system file lock.
Item
FR
SUPER
No.
DISP.
0000
1375
12
SYS H(HD)
2750
0000
0128
14
SYS SC(SD)
0255
0000
0864
15
SYS H(SD)
1728
0000
0001
18
SCH COAR(SD)
0002
0003
0000
0032
19
SCH FINE(SD)
0064
0000
0128
20
AV PHASE
0255
For AJ-HPM100P
0000
0001
25
SYSTEM FREQ
For AJ-HPM100E
0000
0001

Item Settings

Setting
FR
SUPER
No.
DISP.
–1375
Adjusts system phase of analog component (HD) output and HD SDI output (in 13.5 ns
|
|
steps).
0
–: Advances the phase.
+: Delays the phase.
|
|
1375
NOTE:
A reset does not return this setting to its factory default.
An item that flashes can be returned to its factory default by pressing the RESET button.
–128
Adjusts the system phase of the analog composite output and SD SDI output (total variable
|
|
range: ±180°).
0
NOTE:
|
|
A reset does not return this setting to its factory default.
127
An item that flashes can be returned to its factory default by pressing the RESET button.
–864
Adjusts system phase of analog composite output and SD SDI output (in 37 ns steps).
|
|
–: Advances the phase.
0
+: Delays the phase.
|
|
NOTE:
864
A reset does not return this setting to its factory default.
An item that flashes can be returned to its factory default by pressing the RESET button.
0
Adjusts the SCH phase of analog composite output (four 90° positions).
90
180
270
–32
Adjusts the SCH phase of analog composite output (total variable range ±45° or more).
|
|
Changes the SC phase but not the H phase.
0
Covers ±180° in combination with No. 18 SCH COAR(SD).
|
|
32
–128
Adjusts audio output phase relative to video output (in 20.8 µs steps).
|
|
–: Advances audio output phase relative to video output.
0
+: Delays audio output phase relative to video output.
|
|
127
Sets system frequency.
0: 59.94Hz
59.94
1: 50Hz
50
NOTE:
Changing this item will only cause the menu item to flash but the setting is not actually
59.94
reflected to this unit. For the changes to take effect, turn the power off and turn it back
50
on again.
* An underlined setting indicates an initial value.
Settings and brief function description
93
Setup: Item Settings
