DVCPRO P2 SERIES

Advertisement

   Also See for Panasonic DVCPRO P2 Series

   Related Manuals for Panasonic DVCPRO P2 Series

   Summary of Contents for Panasonic DVCPRO P2 Series

  • Page 1

    DVCPRO P2 SERIES...

  • Page 2

    IT-based news gathering (ING). Panasonic has now taken P2 even further with the P2 HD series. Offering HD/SD multi-format capability and multi-codec recording, the new P2 HD cards take you to an era in which HD is fast becoming the mainstream for news gathering and content production.

  • Page 4

    The New Workflows of News — Bringing Greater Reliability to News Acquisition: The P2 card The P2 card far surpasses videotape and discs in reliability. It withstands shock up to 1,500 G and vibration up to 15 G, operates in temperatures from –20 to 60°C, and can be stored in temperatures from –40 to 80°C.

  • Page 5

    New P2 HD Series Continues to Evolve The new P2 HD series offers full high-definition capabilities. In addition to the AG-HVX200 handheld camera-recorder now available, Panasonic will introduce a steady stream of new P2 HD products, including an HD-compatible P2 cam and P2 mobile.

  • Page 6

    card card P2 card Line-up Expands with New 8GB Capacity AJ-P2C008HG H-Series 8GB Memory card AJ-P2C004HG H-Series 4GB Memory card...

  • Page 7

    Super-Compact Cards with Large Capacity and High Speed In developing the P2 card, Panasonic applied some of the same technology that proved so successful in the SD Memory card.* Basically, four SD Memory cards are packaged together to create a single P2 card.

  • Page 8

    Cost-efficient P2 Cam with Outstanding Mobility and Low Power Consumption AJ-SPC700 MEMORY CARD CAMERA-RECORDER (P2 cam)

  • Page 9

    Newly Developed Gamma Curve for News The gamma functions featured in Panasonic VariCam models have earned wide acclaim. Now Panasonic has developed a new gamma *without option,LCD monitor off. curve for the P2 cam: news gamma. This new function, offered in...

  • Page 10

    Voice Memo and Shot Marker If desired, to each clip you can add a simple OK/NG shot marker and a voice memo with an audio comment linked to the time code. You can do this either during or after recording to support post- recording processing.

  • Page 11

    Full-Featured P2 Cam with High Sensitivity, Digital Super Gain and 25p Shooting AJ-SPX900/AJ-SPX800 MEMORY CARD CAMERA-RECORDER (P2 cam)

  • Page 12

    Two Models -- Two Optical Filters to Choose From These two models let you select either a one-wheel or two-wheel optical filter configuration to meet your needs. The two-wheel AJ-SPX900 gives you separate ND (CLEAR, 1/4 ND, 1/16 ND, 1/64 ND) and CC (Cross, 3200K, 4300K, 6300K) filters for detailed image control.

  • Page 13

    Proxy Data Recording* Mount an AJ-YAX800G Proxy Encode Card, and the AJ-SPX900 and AJ-SPX800 record MPEG4 proxy (low-resolution) data — useful for news flash or other studio news system use — onto the card along with the full-resolution data. The three levels of proxy video are available: 1.5Mbps, 768kbps or 192kbps.

  • Page 14: Nonlinear Editing

    deck deck Ideal for use in Existing Mobile Van and Studio Environments and Allows VTR-Like Nonlinear Editing AJ-SPD850 MEMORY CARD RECORDER (P2 deck) (with optional DVD-RAM/R drive AJ-DVD850G)

  • Page 15

    Five P2 card Slots With its five PC card slots, the AJ-SPD850 lets you mount five P2 cards and play a continuous, extended clip recorded in sequence onto multiple cards. Using line input, you can also record a continuous, extended clip onto five P2 cards in sequence. DVCPRO 50/DVCPRO/DV Switchable The AJ-SPD850 records in 25Mbps DVCPRO;...

  • Page 16

    drive drive New P2 Card Drive with IEEE 1394b/USB 2.0 Interface for Both Mac and Windows Support store store Portable Hard Disk Unit that Copies P2 Card Data at High Speeds AJ-PCD20 MEMORY CARD DRIVE (P2 drive) AJ-PCS060G PORTABLE HARD DISK UNIT (P2 store)

  • Page 17

    High-Speed Data Transfer via IEEE 1394b or USB 2.0 The AJ-PCD20 is equipped with an IEEE 1394b (800Mbps) interface in addition to the USB2.0 interface provided on the previous model (AJ-PCD10), enabling it to support both Mac and Windows PC. P2 card driver software is also available for both Mac OS X and Windows XP/2000.

  • Page 18

    Revolutionary HD Potential in the New P2-HD Series As P2 continues to transform the world's news systems, Panasonic takes the next step with the HD-Ready P2-HD series. Following the introduction of the handheld AG-HVX200 DVCPRO HD Camera-Recorder, we are...

  • Page 19

    P2 MOBILE RECORDER Mobile HD/SD Recorder for More Flexible News Gathering With the AJ-HPM100, Panasonic has developed a new P2 mobile recorder that's based on the same design concept as DVCPRO laptop editors. This compact unit comes packaged with six P2 card slots, an LCD monitor, speakers and an editing controller with a jog and shuttle dial.

  • Page 20

    handheld handheld AG-HVX200 DVCPRO HD MEMORY CARD CAMERA-RECORDER Heralding a New Era in News Gathering and Production...

  • Page 21

    0.6 metre in telephoto mode and a wide-angle range that extends to around 32.5mm (35mm equivalent). The lens is also equipped with Panasonic's Optical Image Stabiliser. * Leica is a registered trademark of Leica Microsystem IR GmbH, and Dicomar is a registered trademark of Leica Camera AG.

  • Page 22

    P2 file functions. To download P2 Viewer: http://panasonic.biz/sav/p2/p2viewer/ *Microsoft® Windows 2000 SP4, Microsoft® Windows XP Professional SP2, or newer OS. Microsoft® DirectX 9.0b or newer version must be installed.Full-color (32-bit) display, and an audio function.

  • Page 23

    P2 Optional Accessories P2 Optional Accessories P2 cam (AJ-SPC700/AJ-SPX800/AJ-SPX900) OPTIONS AJ-VF20WBE AJ-VF15BE 2" EVF 16:9/4:3 SWITCHABLE 1.5" EVF FOR 4:3 AJ-MC700 AJ-MH800G MICROPHONE KIT MICROPHONE HOLDER AJ-YAD800G SHAN-TM700 IEEE 1394 INTERFACE BOARD TRIPOD ADAPTRE ANTONBAUER AC ULTRA LIGHT ADAPTOR/BATTERY CHARGER ANTONBAUER ULTRA LIGHT SHAN-RC700 RAIN COVER...

  • Page 24

    P2 cam (FOR AJ-SPX800/AJ-SPX900) OPTIONS AJ-MC900G* AJ-GPS900G STEREO MICROPHONE GPS UNIT * Requires modification to the camera-recorder (for AJ-SPX800/SPX900) mic terminal. Ask your local sales company or dealer for details. (for AJ-SPX800/SPX900) P2 cam SYSTEM CHART AJ-MH800G Microphone Microphone Holder AJ-GPS900G GPS Unit (for AJ-SPX800/SPX900) AJ-MC700...

  • Page 25

    P2 handheld (AG-HVX200) /P2 store (AJ-PCS060G) OPTIONS AG-MC100G CGA-D54S MICROPHONE FOR AG-HVX200 BATTERY PACK (5.4 Ah) FOR AG-HVX200 AND AJ-PCS060G P2 deck (AJ-SPD850) OPTIONS AJ-DVD850G AJ-YA755G DVD-RAM/DVD-R DRIVE SDI BOARD HD/SD LCD MONITORS BT-LH900A 8.4" LCD HD/SD MONITOR AJ-YAD850G AJ-MA75P IEEE 1394 INTERFACE BOARD RACK MOUNT ADAPTER *slide rail, not included...

  • Page 26

    P2 Specifications P2 Specifications AJ-P2C008HG/AJ-P2C004HG MEMORY CARD (P2 CARD) Common Specification Interface: CardBus (PC Card standards) Power Source: DC3.3V ±0.3V Power Consumption: Approx. 1.5W Operating Temperature: –20°C to 60°C Operating Humidity: 5% to 90% (no condensation) Storage Temperature: –40°C to 80°C Storage Humidity: 5% to 90% (no condensation) Weight:...

  • Page 27

    AJ-SPX900/SPX800 MEMORY CARD CAMERA-RECORDER (P2 CAM) General Specification Power Source: DC 12V (11.0V to 17.0V) Power Consumption: 24W (without option, LCD monitor off) 27W (with SDI & IEEE 1394 option, LCD monitor on) Operating Temperature : 0°C to 40°C Storage Temperature: –20°C to 60°C Operating Humidity: 10% to 85% (relative humidity)

  • Page 28

    P2 Specifications P2 Specifications • Composite IN/Composite OUT Video Bandwidth (625i): 25 Hz to 5.5 MHz (–3.0 dB) Video Bandwidth (525i): 30 Hz to 5.5 MHz (–3.0 dB) Y/C Delay: less than 20 nsec Video Input Signal Analogue Component In: BNC x 3 (Y,PB,PR) Y: 1.0 Vp-p, 75 , PB/PR (625i): PB/PR (525i):...

  • Page 29

    AG-HVX200 DVCPRO HD MEMORY CARD CAMERA RECORDER GENERAL Supply Voltage: DC7.2V / 7.9V, Battery or DC Input Power Consumption: 11.6W (when viewfinder is used) 12.0W (when LCD monitor is used) 14.0W (Max) Operating Temperature: 0°C to +40°C Operating Humidity: 10% to 85% (no condensation) Weight: Approx.

  • Page 30

    The P2 Partners The P2 Partners Panasonic has long followed an "open mind" policy that ensures easy use with products made by other manufacturers via interfaces such as IEEE 1394. This gives users the enormous benefit of purchasing new equipment that's compatible with their current hardware and software just with minimum additional investment .

  • Page 31

    • D -Edit HD • DP-Edit www.dayang.com.cn/ • DaletPlus News Suite www.dalet.com • Mpegable DS Decoder www.mpegable.com • CleanEdit www.evs.tv/ • FireStore FS-100 • DV File Converter Pro www.focusinfo.com • NewsEdit™ LT/SC/XT www.thomsongrassvalley.com • Velocity NX/NXG/Q/HD/X • NewsFlash FX • Nexio XS www.leitch.com •...

  • Page 32

    Systems Business Group Austria 2-15 Matsuba-cho, Kadoma, Osaka 571-8503 Bahrain Japan Belgium Phone +81 6 6905 4650 Fax +81 6 6908 5969 Bulgaria https://eww.pavc.panasonic.co.jp/pro-av/ China (Hong Kong Czech Republic +420 236 032 552/511 Denmark Egypt Finland, Latvia, Lithuania, Estonia France...
