Monitoring and Analyzing Switch Operation
Traffic Mirroring
Mirror Session Identity from
the Source Switch (Session 2)
Switch-D(config)# mirror endpoint 10.10.10.119 9400 10.10.40.1 port b10
Figure B-34. Example of Configuring Remote Mirroring for Session 2 on the Destination Switch
Switch-A(config)# mirror 2 remote ip 10.10.10.119 9400 10.10.40.1
1
Caution: Please configure destination switch first.
Do you want to continue [y/n]? y
2
Switch-A(config)# interface c12 monitor all in mirror 2
Figure B-35. Example of Configuring a Remote Mirroring Session for Traffic Inbound on a Port
B-68
3. Configure switch A to mirror session 2 to the destination interface for
port B10 on switch D. Use a randomly selected UDP port number of 9400.
(Refer to the Note on page B-67.) If you need information on selecting
UDP port numbers to use for remote mirroring, refer to the syntax
description on page B-42.
Interface to
Monitor
Uses the source IP address and random UDP port number to identify session 2 mirrored
1
traffic from VLAN 10, and specifies the destination IP address for this traffic. (The mirror
exit port for this traffic is a member of the VLAN identified by the destination IP address.)
2
Configures port C12 as the source of traffic to mirror (inbound).
Mirror Session Destination
IP Address
Mirror Session
2 Identity
Directional Criteria for
Selecting Traffic To Mirror
Mirror Session
Exit Port
Mirror Session
Destination
Mirror
Session
