Monitoring and Analyzing Switch Operation
Traffic Mirroring
ProCurve(config)# mirror 2 name test-10 remote ip 10.10.10.1 8010 10.10.30.2
Caution: Please configure destination switch first.
Do you want to continue [y/n]? y
ProCurve(config)# ProCurve(config)# interface b1 monitor all both mirror 2
Figure B-22. Example of Configuring a Remote Mirroring Session and Corresponding Source
ProCurve_5400(config)# show monitor 2
Network Monitoring
Session: 2
ACL: no ACL relationship exists
Mirror Destination:
UDP Source Addr
---------------
10.10.10.1
Monitoring Sources
------------------
Port: B1
Figure B-23. Example of Output for a Remote Mirroring Session
B-60
Syntax: show monitor < 1 - 4 | name < name-str >
Direction: For the selected interface, indicates whether mirrored
traffic is entering the switch (in), leaving the switch (out), or
both.
For example, if you configure remote mirroring session 2 as shown in figure
B-22, show monitor 2 displays the session 2 configuration in figure B-23, below.
Session Name: test-10
IPv4
UDP port
--------
8010
Direction
---------
Both
If the selected session is configured for local mirroring, using show monitor
with the session number displays a subset of the types of information dis-
played for a remote mirroring session. For example, suppose a session is
configured as follows for local mirroring:
Use "1" as the session number.
■
■ Use "Detail" as the session name.
Use ACL 100 (previously configured on the switch) to mirror the inbound
■
traffic on port B1.
Send the mirrored traffic to (exit) port B3.
■
UDP Dest Addr
---------------
10.10.30.2
Status
--------
active
If there are no mirroring sources
configured for a given mirroring
session, these two fields are empty.
