Configuring IP Addressing
Loopback Interfaces
N o t e
8-18

Displaying Loopback Interface Configurations

To display the list of loopback interfaces which have been assigned IP
addresses, enter the show ip command.
In the show ip command output, information about configured loopback
interfaces is displayed below other IP configuration parameters, such as
packet time-to-live (TTL) and ARP age-out values, and VLAN IP configura-
tions. The following example displays the IP addresses configured for two
user-defined loopback interfaces (lo1 and lo2).
ProCurve> show ip
Internet (IP) Service
IP Routing : Enabled
Default TTL : 64
ARP Age : 20
VLAN IP Config IP Address Subnet Mask Proxy ARP
-------- --------- ---------- ----------
DEFAULT_VLAN
VLAN2
VLAN3
Loopback Addresses
Loopback IP Config
-------- ----------
lo1 Manual
lo2 Manual
lo2 Manual
Figure 8-7. Example of show ip Command Output
The default loopback interface (lo0) with IP address 127.0.0.1 is not displayed
in the show ip command output because it is permanently configured on the
switch. To display the default loopback address, enter the show ip route
command as shown in Figure 8-8.
Manual 10.0.8.121
Manual 192.168.12.1 255.255.255.0
Disabled
IP Address
----------
172.16.110.2
172.16.112.2
172.16.114.1
-------
255.255.0.0 No
No
Subnet Mask
---------------
255.255.255.255
255.255.255.255
255.255.255.255
