9 General Specifications

9.1

Printer Specifications

Print System
Print Technology
Print Head
Print Speed
Character Pitch
Print attributes in
all character
pitches
Character Size
Font Matrix
Paper Feed
*) Only with ESC/P (sub-/superscript, 15 CPI) and MTPL Micro-script
**) Reduced matrix, selectable by menu, named Ultra-Draft
Mono-chrome serial impact dot matrix
Uni-/bi-directional logic seeking for text and graphics
Number of pins:
Firing frequency:
Pin diameter:
Distance between pins:
Life:
Pitch HS Draft
10 CPI 500
12 CPI 500
15 CPI *) 500
15 CPI 500
17.1 CPI 286
20 CPI 333
17.1 CPI **) 571
20 CPI **) 680
5 / 6 / 7.5 / 8.6 / 10 / 12 / 15 / 17.1 / 20 CPI (characters per inch)
Double width / italics / right justification / shadowed / auto centered / double height
/ bold / proportionally spaced / underlined / overlined / superscript / subscript;
Scalable with special LQ-2170 fonts
Height: 3.32 mm (inclusive descenders)
Width: max. 2.43 mm
Pitch HS Draft
10 CPI
24x8/80H
12 CPI
24x8/96H
15 CPI *)
16x8/120H
15 CPI
24x8/120H
17.1 CPI
24x12+2/240H
20 CPI
24x10+2/240H
17.1 CPI **)
24x06+1/240H
20 CPI **)
24x05+1/240H
Feed speed:
Feed first line (6lpi): 43 ms
View / Tear position:
Reverse motion: up to max form length of 14 inches
24 pins (2 x 12; staggered)
Normal mode: 2 kHz
0.25 mm
horizontal 1/20 inch, vertical 1/90 inch
500 million strokes/pin @ Draft mode
Draft NLQ
333 222
400 267
500 333
500 167
285 190
333 222
--- ---
--- ---
Draft
24x12/120H
24x10/120H
16x8/120H
24x8/120H
24x12+2/240H
24x12+2/240H
---
---
5 ips (tractor and friction)
5 ips
107
LQ in CPS
(characters per second)
111
133
167
167
190
222
---
---
NLQ LQ
24x18/180H 24x36/360H
24x15/180H 24x30/360H
16x12/180H 16x24/360H
24x18+6/360H 24x18+6/360H
24x18+3/360H 24x18+3/360H
24x15+3/360H 24x15+3/360H
--- ---
--- ---
(Matrix/DPI)
