Parts description

Control Panel
1
Latch
2
Front Cover
3
Power Switch
4
Hand Wheel
5
Paper Support
6
Top Covers 1&2
7
Head Gap Lever
8
Paper Path Lever
9
Upper Friction
10
Power Socket
11
Interfaces
12
Mute Cover Latch
13
Print Head
14
Ribbon Cartridge
15
Tractors
16
Paper Guides
17
Left/Right
Cut Sheet Support
18
LED: The 2-line LED with 4 keys panel indicates the
operating status and allows simple settings of the printer;
LCD: A LCD display and two keys indicates the operating
status and allows simple settings of the printer.
Sliding it down unfolds the cut sheet support.
Unlocking the front cover unfolds the cut sheets support.
Turns on and off the printer.
Turn the knob to load or clear the paper. It should be
inserted the full way until you can hears some sort of
"Click".
At slanted position, it stacks cut sheets; at flat position, it
separates fanfold printouts from incoming forms.
Protect the internal parts and reduce the noise.
Adjusts the gap between the print head and various
form thickness.
Selects various paper sources.
Guides the form when cut sheets or fanfold forms are used.
A power cord is plugged into the socket to supply the
power.
The interface cable of the host computer is plugged into
one of the interfaces.
You must open it before you open the top cover 1.
Utilizes 24 needles to strike on ink ribbon and paper.
Holds the ink ribbon fabric.
Holds and transports fanfold forms.
Sliding the guides varies the form width and the left
margin on a cut sheet.
A flat surface supports a sheet or multi-part form.
