Tally Dascom 2610
2. Static assignment using the operator panel:
◆ Press < Setup >, then < Menu >
.
◆ Press < Next > until the I/O selection appears. Select < I/O >.
◆ Press < Next > until the ETH-INT selection appears. Select < ETH-INT >, then< IP Addr >
◆ Enter the value for Octet 1by pressing < OCTET 1 >. Use the forward and backward
arrows to increment/decrement the number. When finished with each entry press
< Set > which will set the currently displayed value. To exit out without changing the value
press < Exit >. Enter the Octet 2 value in the same way, pressing < OCTET 2 >. To get to
Octet 3 and Octet 4, select < Next > and then select <OCTET 3> and < OCTET 4 >.
◆ Enter the default Gateway and Subnet mask in the same way. < Gateway > is available
from the screen you are returned to. Press < Next > to select < Subnet >.
◆ Enter the IP address get method under the selection <IP Get M>. Select <Static>.
3. BOOTP IP address assignment:
◆ Press <Setup>, then <Menu>
.
◆ Press <Next> until the I/O selection appears. Select <I/O>.
◆ Press <Next> until the ETH-INT selection appears. Select <ETH-INT>.
◆ Press <Next> until the IP Get M selection appears. Select <IP Get M> Select <BOOTP>
◆ Obtain the Ethernet MAC address by printing the "Current Settings" configuration page,
Turn off printer.
◆ Configure your BOOTP server with desired IP address and MAC address.
◆ Turn on printer.
◆ Verify that the printer network interface received an IP address by printing the "Current
Settings" configuration page or in the operator panel menu.
50
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the 2610 and is the answer not in the manual?
Questions and answers
Hello there, I had problem with printer tally dascom 2610+ It can't print invoice But when we test print it work Please. Help
The Dascom 2610 printer may be unable to print invoices despite successful test prints due to one or more of the following reasons:
- The interface cable may not be securely connected to both the printer and the computer.
- The printer driver selected in the software may not match the emulation setting on the printer.
- Incorrect software or printer settings may be used.
- There may be an issue with the computer or interface settings.
- The paper select lever may be in the wrong position, causing the printer to go offline.
Check and correct these settings to resolve the issue.
