2 Site preparation

The BL860c i2 and i4 Server Blades do not have cooling or power systems. Cooling
and power is provided by the c-Class enclosure.
IMPORTANT:
to equalize to the temperature and humidity of the installation facility after removing
the shipping materials. A minimum of one hour per 10° C (50° F) of temperature
difference between the shipping facility and installation facility is required.

Server blade dimensions and weight

Table 1 Server blade dimensions and weight for the BL860c i2 and i4
Dimensions
Height
Width
Depth
Weight
Table 2 Blade Link dimensions and weight
Blade Link type
SBL1 (BL860 i2)
BL1 (BL860 i4)
SBL2 (BL870 i2)
BL2 (BL870 i4)
SBL4 (BL890 i2)
BL4 (BL890 i4)

Enclosure information

All six configurations are supported in HPE c7000 and c3000 Enclosures.
For more enclosure information see:
http://www.hpe.com/servers/bladesystem/enclosures.

Enclosure environmental specifications

NOTE: This information is for both c3000 and c7000 Enclosures.
Specification
Temperature range
Operating
Non-operating
Wet bulb temperature
Operating
To avoid hardware damage, allow the thermal mass of the product
value
36.63 cm (14.42 in.)
5.14 cm (2.025 in.)
48.51 cm (19.1 in.)
Unloaded: 8.6 kg (19 lb)
Fully loaded: 11.3 kg (25 lb)
Height
44 mm (1.73 in)
44 mm (1.73 in)
44 mm (1.73 in)
1
Width Weight
51 mm (2 in) .5 lb (.22 kg)
106 mm (4.17 in) 1 lb (.45 kg)
212 mm (8.34 in) 2 lb (.90 kg)
Value
10° C to 35° C (50° F to 95° F)
-30° C to 60° C (-22° F to 140° F)
28º C (82.4º F)
7
