Table 5 Power States
Power States
Standby power
Full power
Off
Powering on the server blade
Use one of the following methods to power on the server blade:
NOTE:
To power on blades in a conjoined configuration, only power on the Monarch
blade. See
" Blade Link bay location rules"
blade.
Use a virtual power button selection through iLO 3.
Press and release the Monarch power button.
When the server blade goes from the standby mode to the full power mode, the blade
power LED changes from amber to green.
Powering off the server blade
Before powering down the server blade for any upgrade or maintenance procedures,
perform a backup of critical server data and programs.
Use one of the following methods to power off the server blade:
NOTE:
To power off blades in a conjoined configuration, only power off the Monarch
blade.
Use a virtual power button selection through the iLO 3 GUI (Power Management,
Power & Reset) or the iLO 3 TUI commands.
This method initiates a controlled remote shutdown of applications and the OS
before the server blade enter standby mode.
Press and release the Monarch power button.
This method initiates a controlled shutdown of applications and the OS before
the server blade enter standby mode.
Press and hold the Monarch power button for more than 4 seconds to force the
server blade to enter standby mode.
This method forces the server blade to enter standby mode without properly
exiting applications and the OS. It provides an emergency shutdown method in
the event of a hung application.
Installing the Blade Link for BL860c i2, BL860c i4, BL870c i2,
BL870c i4, BL890c i2, or BL890c i4 configurations
IMPORTANT:
Server Blade
Front Panel Power
Installed in
Button Activated?
Enclosure?
Yes
Yes
No
Without an attached Blade Link, the server blades will not power on.
Standby Power
Applied?
No
Yes
Yes
Yes
No
No
for rules on the definition of the Monarch
DC Power
Applied?
No
Yes
No
20
