NOTE: Before installing the Blade Link for BL870c i2, BL870c i4, BL890c i2, or
BL890c i4 server blades, make sure the following statements are true:
All blades have the same CPU SKUs.
All blades have the same hardware revision (only use BL860c i2, BL860c i4,
BL870c i2, BL870c i4, BL890c i2, or BL890c i4 Server Blades).
All blades have CPU0 installed.
All blades have the same firmware revision set.
All blades follow the memory loading rules for your configuration.
The enclosure OA firmware is compatible with the blade firmware.
The Monarch blade has an ICH mezzanine card installed.
The proper Blade Link is being used for your configuration.
To check on the blade hardware revisions and CPU SKUs, go to the Command Menu
in the iLO 3 TUI and enter the DF command. This dumps the FRU content of the
blades.
NOTE: If you will be upgrading an initial installation, see the user service guide for
more information on server blade upgrades.
Blade Link bay location rules
Number of
conjoined
Class blades
BL1 1
(standard
for BL860c
i2 and
BL860c i4)
Supported Blade location
enclosures rules
c7000 No specific bay
location rules for
blades
c3000
Partner blade
half-height bay
number / Server
Partner blade blade full-height
support? bay number
Yes Bottom half-height
adjacent bay,
paired with the
server blade in
full-height bays
1&2, 3&4, 5&6, or
7&8.
Half-height bay 8,
paired with the
server blade in
full-height bay 3.
CAUTION:
bay mini-divider
must be installed
in the c3000
enclosure to
ensure the partner
blade is inserted
correctly. Failure
to install the bay
mini-divider might
result in damage
to the blade or
enclosure when
installing the
partner blade.
The
