c3000 divider
a. Push the divider toward the back of the enclosure until it stops.
b. Slide the divider to the left to disengage the tabs from the wall.
c. Rotate the divider clockwise.
d. Remove the divider from the enclosure.

Installing interconnect modules

For specific steps to install interconnect modules, see the documentation that ships
with the interconnect module.

Interconnect bay numbering and device mapping

HPE BladeSystem c7000 Enclosure
16
