39
Switch
1
2
3
1
0
0
1
1
0
1
0
1
1
1
1
1
0
0
1
1
0
1
0
1
1
1
1
0
X
X
5. To exit tune mode, simply set DIP switch 1 back to the off position (up for off). The CFG LED will go off
and DCP polling may resume.
9
Configuration
9.1
DIP Switches
Switches 1-2:
Address Selection
(DCPx only)
The DIP switches are numbered 1 to 8 from left to right. When angled UP, a DIP switch is OFF (0). When
angled DOWN, the DIP switch is ON (1). The default setting is all switches OFF, which configures the unit as a
2400 baud, DCPx responder for address 1.
Note: The 232 Chain port is reserved for future use.
4
0
Reserved.
0
Adjust the modem transmit level one increment higher.
0
Adjust the modem transmit level on increment lower.
Transmit a continuous space level tone of 2200 Hz on the modem
0
output line.
Transmit a continuous mark level tone of 1200 Hz on the modem
1
output line.
1
Turn off the modem transmitter.
1
Adjust modem transmitter 10 increments lower.
1
Adjust modem transmitter 10 increments higher.
X
Exit tune modem mode.
Table D. DIP switch settings and command descriptions
Switches 3-5, 7 are reserved and
should be left in the OFF position
Exp Cfg
Exp Cfg
Switches 6:
Baud Rate Selection
Fig. 47. Front Exp Cfg DIP switches
Command
Switches 8:
Enables the use of the
DIP Switch configuration
