Front Panel Connections

Craft Port
The craft port, LED displays, DIP Switches and Modem Tune are accessed via the front panel, as seen in Figure
3.
5

Rear Panel Connections

Dual Power
Inputs
3/4 Amp
GMT Fuse
Connectors for power feeds, alarm inputs, control outputs, and communication lines are on the back panel of the
NetGuardian 480, as shown in Figure 4.
LED Displays
Fig. 3. The NetGuardian 480 G2 Front Panel Controls
Discretes 49 - 80,
Controls 1 - 4
Fig. 4. NetGuardian 480 G2 rear panel connections
DIP Switch
Configuration
Modem
Tune
Discretes 1 - 48
202 Jack
10BaseT
Ethernet jack
Serial
Serial
jack
Chain jack
