NetGuardian 480 G2 (202/LAN model)
202 4-Pin Connector
Tx- Tx+ Rx+ Rx-
Fig. 7b NetGuardian 480 G2
(202 4-pin, Serial, 10BaseT ports version)
RJ45 202 Serial
Connection
8 Tx+
7
6 Rx-
5
4
3 Rx+
2
1 Tx-
