1.3 Board Layout

Socket 478 Intel Pentium 4 processor
up to 3.2GHz+ with 800MHz FSB
I
Intel865G Chipset
w/integrated VGA
Controller
Max2GB DDR 400/Dual
Channel Memory in 2
DIMM Slots
Figure 1-1: Peak735 Front Layout
ATX 5V Standby
Power Connector
Serial ATA Connector x 2
Intel 82547EI Gigabit/CSA
Ethernet Controller or Intel
82562EX 10/100 LCI Ethernet
Controller
8
Intel 82551QM
10/100 Ethernet
Controller
Dual LAN
