2.2 Setting Jumpers

A jumper is the simplest kind of electric switch. It consists of two metal pins and a

cap. When setting the jumpers, ensure that the jumper caps are placed on the

correct pins. When the jumper cap is placed on both pins, the jumper is SHORT.

If you remove the jumper cap, or place the jumper cap on just one pin, the jumpr is

OPEN. Please see the following illustrations:

The illustrations on the right show

a 2-pin jumper. When the jumper

cap is placed on both pins, the

jumper is SHORT . If you remove

the jumper cap, or place the

jumper cap on just one pin, the

jumper is OPEN .

These illustrations show a 3-pin

jumper. Pins 1 and 2 are SHORT.

Open (Off)

Figure 2-1 : How to Set Jumpers

Short (On)
