2.1 Functions of Jumpers

You can use jumpers to set configuration options. The table below defines
function of each jumper:
Connector
J1
AC'97
J2
Primary IDE
J3
SATA 0
J4
Secondary IDE
J5
SATA 1
J6
USB 2.0 Connector
J7
USB Exernal Power Connector
J8
Floppy
J9
DVI Connector(optional)
J10
CPU Fan
J11
System Fan
J12
COM1
J13
COM2
J14
PIO
J15
ATX Connector
J16
External Keyboard
JP2
Speaker
JP4
IDE LED
JP7
GPI/O Port
JP8
Keylock/Power LED
JP9
IR Connector
JP10
82551 LAN Speed 100 LED
JP11
82551 LAN ACT/LINK LED
JP12
ATX Push Button
JP13
82747/82562 LAN speed 100 LED
JP16
82747 LAN speed 1000 LED
JP17
Reset
JP18
82747/82562 LAN ACT/LINK LED
JP20
SMBUS
CON1
VGA Connector
CON2
82551 LAN Connector
CON3
82547/82562 LAN Connector
CON4
AUX+12V Power Connector
CON5
Keyboard+Mouse Connector
Table 2-1: Functions of Jumpers
Function
12
