CON3:82547/82562 RJ45 connector
Pin
Definition
1
LAN2_MDX_0P_TXP
3
LAN2_MDX_1P_RXP
5
LAN2_MDX_2N
7
LAN2_MDX_3P
9
LAN2_LINK1000
11 LAN2_LINK_UP
CON4: AUX +12V Power Connector
Pin
Definition
1
GND
3
+12V
CON5: Key board + mouse connector
Pin
Definition
1
KBDATA
3
GND
5
KBCLK
Pin
Definition
2
LAN2_MDX_0N_TXN
4
LAN2_MDX_2P
6
LAN2_MDX_1N_RXN
8
LAN2_MDX_3N
10 +3VSBY
12 LAN2_ACTIVITY
Pin
Definition
2
GND
4
+12V
Pin
2
MOUSEDATA
4
+5V
6
MOUSECLK
21
