Nexcom PEAK 735 Series User Manual page 21

JP13:82747EI/82562EX LAN External SPEED 100 LED connector
Pin Definition
1 +3VSBY
JP16:82747EI LAN External SPEED 1000 LED connector
Pin Definition
1 +3VSBY
JP17: Hardware Reset connector
Pin Definition
1 RESET
JP18: 82747EI/82562EX LAN External ACTIVE&LINK LED connector
Pin Definition
1 LINK_UP
JP20: SMBUS connector
Pin Definition
1 SMBCLK
CON1:VGA connector
Pin Definition
1 RED
3 BLUE
5 GND
7 GND
9 +5V
11 NC
13 HSYNC
15 DDCCLK
CON2:82551 RJ45 connector
Pin Definition
1 LAN1_TXP
3 LAN1_RXP
5 TERMPLANE
7 TERMPLANE
9 SPEED_LAN1
11 LILED_LAN1
Pin Definition
2 LINK100
Pin Definition
2 LINK1000
Pin Definition
2 GND
Pin Definition
2 ACTIVITY
Pin Definition
2 SMBDATA
Pin
2 GREEN
4 NC
6 GND
8 GND
10 GND
12 DDCDAT
14 VSYNC
Pin Definition
2 LAN1_TXN
4 TERMPLANE
6 LAN1_RXN
8 TERMPLANE
10 +3VSBY
12 ACTLED_LAN1
20
Definition
