i.e. D3=1, Enables WDT
OR
al, 00001000b ; Enable the WDT
After finishing the above settings, you must output the Control Register' s value to
WDT Configuration Port. Then WDT will start according to the above settings.
MOV
dx, F2h
OUT
dx, al
Appendix B:GPIO USER GUIDE
DIGITAL I/O UESD PORT 801
I 3
{
; Setting WDT Configuration Port
; Output the Control Register Value
I 2
I1
I0
Input
JP17
IN 0
1
IN 1
3
IN 2
5
IN 3
7
O3
O2
O1
} {
Output
OUT 0
2
OUT 1
4
OUT 2
6
OUT 3
8
70
O0
}
