System Monitor

-Derived from Super IO ITE 8712F-A to support system monitor
-8 voltage (For +1.5V, +3.3V, +5V, -5V, +12V, -12V, Vcore and +5VSTBY)
-Fan speed connector x 2 (one is for CPU, while the other is for system)
-Temperature sensor x 2 (one is for internal CPU, while the other is for external system)
Real Time Clock
-On-chip RTC with battery back-up
-External Li battery x 1
Watchdog Timer
-Watchdog timeout programmable by software from 1, 2, 4, 8, 16, 32... to 128 seconds
PCI to ISA Bridge & ISAMAX Support
-ITE 8888F x1 PCI to ISA Bridge -Provide 64mA driving capability to
maximize ISA signals for supporting ISA cards up to 20 on the
backplane ISA slot
Dimensions
-338.58mm(L) x 122mm(W) (13.3"(L) x 4.8"(W)
Power Requirements
-+5V, +12V, -12V, ATX/AT

Power Consumption:

Model
CPU
+12V
+5V
+3.3V
+5Vsb
Environments
-Operating temperature: up to 60°C, below -20°C (under certain condition)
-Storage temperature: -20°C to 80°C
-Relative humidity: 10% to 90% (Non-condensing)
Certification
-CE approval
-FCC
PEAK 735VL2 (G)
3.0G
2.4G
6.5A
4.5A
5.4A
4A
0.5A
0.5A
0.5A
0.5A
7
