On-Chip Serial ATA Setting
On-Chip Serial ATA
The setting is used to specify te SATA controller.
Settings:
Disable, Auto,
If <Combined Mode> is selected, PATA and SATA will be combined.
If <Enhanced Mode> is selected, PATA and SATA will both be enabled.
If <Auto> is selected, PATA and SATA will be arranged by BIOS, and you will be able to
see the IDE Device Status listed in the Standard CMOS Features.
Serial ATA Port O/I Mode
Select a compatible mode for Port 1 and Port 2 from the Award Setting to the Chipset
Setting:
Primary Master
Primary Slave
Secondary Master
Secondary Slave
Primary Master
Secondary Master
SATA 1 Master
SATA2 Master
Combined Mode,
Compatible Mode w/Serial ATA Port 1 set to Primary Master
Primary Slave
Secondary Master
Secondary Slave
Compatible Mode w/only serial ATA Enabled and Port 1 set
to Primary Master
Secondary Master
Enhance mode w/Port 1 set to Native Mode Master
Enhance mode w/Port2 set to Native Mode Master
Enhanced Mode,
30
SATA only
