2.5 Connector Pin Definition

AC' 97 connector
Pin
1 AC_SDOUT_R
3 AC_RST#
5 AC_SYNC
7 AC_SDIN0
9 AC_BTCLK
J2/J4: IDE connector
Pin Definition
1 IDRST#
3 PDD7A
5 PDD6A
7 PDD5A
9 PDD4A
11 PDD3A
13 PDD2A
15 PDD1A
17 PDD0A
19 GND
21 PDREQA
23 PDIOW#A
25 PDIOR#A
27 PIORDYA
29 PDDACK#A 30 GND
31 HDIRQ14
33 PDA1A
35 PDA0A
37 PDCS#1
39 IDEACTP#
Definition Pin
Pin Definition
2 GND
4 PDD8A
6 PDD9A
8 PDD710A
10 PDD711A
12 PDD712A
14 PDD713A
16 PDD714A
18 PDD715A
20 NC
22 GND
24 GND
26 GND
28 IDE-PD1
32 NC
34 P66 DET
36 PDA2A
38 PDCS#3
40 GND
Definition
2 +5V
4 GND
6 +12V
8 AC_SDIN1_R
10 AC_SDIN2_R
Pin Definition
1 IDRST#
3 SDD7A
5 SDD6A
7 SDD5A
9 SDD4A
11 SDD3A
13 SDD2A
15 SDD1A
17 SDD0A
19 GND
21 SDREQA
23 SDIOW#A
25 SDIOR#A
27 SIORDY A
29 SDDACK#A 30 GND
31 HDIRQ14
33 PDA1A
35 SDA0A
37 SDCS#1
39 IDEACTP#
16
Pin Definition
2 GND
4 SDD8A
6 SDD9A
8 SDD710A
10 SDD711A
12 SDD712A
14 SDD713A
16 SDD714A
18 SDD715A
20 NC
22 GND
24 GND
26 GND
28 IDE-PD2
32 NC
34 S66 DET
36 SDA2A
38 SDCS#3
40 GND
