If water WILL NOT be below bubbler level: remove retaining ring, lens, nozzle nut, and nozzle.
• Retrieve the following parts:
• SCHED 40 PVC cut to be just above the water level
• SCHED 40 PVC threaded male 1.5" to 1.5" Slip Adapter
•
SCHED 40 PVC Slip to 1.5" Threaded Female Adapter
• SCHED 40 PVC 1.5" Threaded Plug
• Glue the pipe to the threaded male adapter.
•
Glue the other end of the pipe (top) to the threaded female adapter.
•
Apply thread seal tape to the threaded male adapter and thread the adapter into the side
replacing the nozzle nut. (See image on the following page)
• Use compressed air or some other source to remove all the water from the lines.
• Apply thread seal tape to the Threaded Plug and then thread the Plug into the female adapter
to finish sealing the system.
•
If using an Accent Light, keep the light in the port. If you are not using an Accent Light, make
sure that the ColorLogic Bubbler NozzleThreaded Plug and an O-Ring are screwed into the
lighting port.
IMPORTANT: Do not use glue within the ColorLogic
REPLACEMENT ORDER: In the event the plaster shield is misplaced, please Visit www.
hayward.com. Search for GLX-BKT.
