Water Bowl
Water Feature With LED Lighting
Owner's Manual
WFBRNDBRS
WFBRNDBRNZ
WFBRNDCLR
WFBRNDCPR
WFBRNDGRY
WFBRNDNAT
WFBRNDPEW
Hayward Industries
400 Connell Drive, Suite 6100
Berkeley Heights, NJ 07922
Phone: (908) 355-7995
www.hayward.com
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Contents
Introduction............................2
Installation.............................2
Plumbing.........................5
Electrical Wiring......................6
Bowl Installation.....................9
Operation..............................10
Maintenance.........................12
Replacement Parts................13
Warranty...............................14
WFBSQRBRS
WFBSQRBRNZ
WFBSQRCLR
WFBSQRCPR
WFBSQRGRY
WFBSQRNAT
WFBSQRPEW
LBCUS11100
LBCUS11150
1001810 RevA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hayward WFBRNDBRS
Summary of Contents for Hayward WFBRNDBRS
-
Page 1: Table Of Contents
Replacement Parts....13 Warranty.......14 WFBRNDBRS WFBSQRBRS WFBRNDBRNZ WFBSQRBRNZ WFBRNDCLR WFBSQRCLR WFBRNDCPR WFBSQRCPR WFBRNDGRY WFBSQRGRY WFBRNDNAT WFBSQRNAT WFBRNDPEW WFBSQRPEW LBCUS11100 LBCUS11150 Hayward Industries 400 Connell Drive, Suite 6100 Berkeley Heights, NJ 07922 Phone: (908) 355-7995 www.hayward.com USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... - Page 2 WARNING - Electrical shock hazard. Damage to wiring can cause severe injury or death. To reduce the risk of electric shock replace damaged wiring immediately. Locate conduit to prevent abuse from lawn mowers, hedge trimmers and other equipment. SAVE THESE INSTRUCTIONS USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
-
Page 3: Introduction
It is recommended to keep the unit in its original packaging until the site is prepared for installation. What's Included Refer to the table and graphic below for a list of all items included with the Hayward Water Bowl. Item # Part Description... - Page 4 USE ONLY HAYWARD GENUINE REPLACEMENT PARTS USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
- Page 5 Use individual flow control valves for bowls plumbed at different distances. Use looped plumbing for bowls plumbed at the same distance. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
-
Page 6: Plumbing
Finish Material Finish Material Earth Earth Step 6: Finish plumbing water line, electrical line, and drain line as shown in the overview diagram on page 3. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... -
Page 7: Electrical Wiring
High Voltage from Transformer Manual Wall Switch Omni Control Relay Hayward LJBUY00PP1 Junction Box LED Light Assembly Service Loop Grommet Total distance of cable between LED Light and Transformer should not exceed 150 feet. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... - Page 8 Transformer Step 3: Low Voltage Transformer Wiring Refer to the following graphic when using a Hayward 300W transformer. For other transformers, refer to their included instructions. Be sure to follow all NEC and local codes when wiring. Use 14V tap...
- Page 9 Omni Standard Relay Wiring Hot (black) Connection to transformer Neutral (white) Connection to transformer Ground (green) Connection to transformer Omni Smart Relay Wiring Neutral Line 1 in Load 1 out Neutral Black/White Black Red/White Gray USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
-
Page 10: Bowl Installation
Place the base pad over the niche collar as shown on the following page. For square bowl installations, make sure that the edge of the base pad is aligned with the edge of the pool deck. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... -
Page 11: Operation
To activate the light, simply turn on the switch powering the transformer. To deactivate the light, turn off the switch. To advance to the next light program (fixed color or color show), turn the switch off, then back on again within 10 seconds. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... - Page 12 15 seconds for quick clear view of your pool, then go to the last fixed color or color show that was running. Note: Do not power cycle the light during the first 15 seconds of white to preclude risk of loss of synchronization with other connected lights. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
-
Page 13: Maintenance
It is recommended to either cover the bowl or fill it will pool anti-freeze. Completely drain water from the water supply line and the bowl. Unscrew the water spout assembly from the center of the bowl and store it someplace safe. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... -
Page 14: Replacement Parts
Re-install the gasket, retaining nut, and water spout assembly in the center of the new bowl. Replacement Parts Part No. Description GLXWBNICHE Bowl Niche Replacement Kit GLXWBGSK Bowl Gasket Replacement Kit GLXWBBKHD Bowl Bulkhead and Nut USE ONLY HAYWARD GENUINE REPLACEMENT PARTS... -
Page 15: Warranty
Aqua Plus and SwimPure chlorination products to be free of defects in materials and workmanship, under normal use and service, for a period of three (3) years. Hayward also warrants its Aqua Trol chlorination products to be free of defects in materials and workmanship, under normal use and service for a period of one (1) year. - Page 16 Hayward is a registered trademark of Hayward Industries, Inc. © 2022 Hayward Industries, Inc. All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties.
