- Page 1 Sense & Dispense Troubleshooting Guide AQL-CHEM & AQL-CHEM2(-240) AQL-CHEM3-120/240 Copyright 2014 Hayward Industries Inc.
-
Page 2: Table Of Contents
Table of Contents Check System: ‘pH Low’ Important safety instructions Pg. 1 Pg. 11-13 Check System: ‘pH High’ Important Information and Compatibility Pg. 2 Pg. 14-17 Check System: ‘pH Timeout – Chk Pg. 3 Pg. 18-20 Maintenance feedr’ Check System: ‘pH Calibration Error’ Pg. - Page 3 Sense & Dispense Diagnostics Warning High Voltage Electrocution Hazard Hazardous voltage can shock, burn, cause serious injury and or death. To reduce the risk of electrocution and or electric shock hazards: • Only qualified technicians should remove the panel • Replace damaged wiring immediately •...
- Page 4 Important Information • Sense and Dispense™ is designed for use with the following Goldline Controls: ProLogic ™ (Version 3.0 or greater) Aqua Plus ™ (Version 3.0 or greater) AquaRite Pro ™ • In all cases, verify that proper water flow is passing through the flow cell. •...
-
Page 5: Maintenance
Maintenance Recommended probe maintenance schedule: Residential – at least once every three months. Commercial – every 30 days. Important Maintenance Information: 1. Probes must be clean and free of oils, mineral deposits, and contamination in order to function properly. 2. Probe tips must be kept wet at all times, if left out of water or storage solution the probes will dry out and permanent damage will result. -
Page 6: Maintenance: Probe Cleaning
Maintenance – Probe Cleaning Note: During the cleaning process it is crucial to keep the tips of both the ORP and pH probes wet. If the probes dry out they will be incapable of providing an accurate reading. Step 1 Step 3 Disconnect the probe connectors Clean the probe tip and white reference area... -
Page 7: Calibrating The Ph Probe (Pro Logic)
Calibrating the pH Probe (Pro Logic) Always verify that the pH probe is clean prior to running the calibration procedure. Also, when testing the pH reading independently, it is important to obtain test water from the flow cell chamber (where the probes measure the water). Step 1 Step 4 Press the ‘Menu’... -
Page 8: Calibrating The Ph Probe (Aqua Rite Pro)
Calibrating the pH Probe (Aqua Rite Pro) Always verify that the pH probe is clean prior to running the calibration procedure. Also, when testing the pH reading independently, it is important to obtain test water from the flow cell chamber (where the probes measure the water). Step 1 Step 4 Press the ‘Settings’... -
Page 9: Resetting The Ph/Orp Timeout Error
Resetting the pH/ORP Timeout Error ProLogic Aqua Rite Pro Step 1 Step 1 Press the ‘Menu’ button until the ‘Default Menu’ appears. Press the ‘Info’ button shown above. The ‘Info Menu’ will appear. Step 2 Step 2 Press the right arrow button until the ‘pH/ORP Timeout – Press the right arrow button until the ‘pH/ORP Chk Feedr’... - Page 10 Check System Light On CSM Comm Error ‘CSM Comm Error’ (Chemistry Sensing Module) will appear with the sensing module is not communicating with the main circuit board. Verify the CSM cable is not cut, With the power off, verify the CSM kinked or damaged in any way.
- Page 11 Check System Light On CSM Comm Error ‘CSM Comm Error’ (Chemistry Sensing Module) will appear with the sensing module is not communicating with the main circuit board. Verify the location of the flow cell. Measure for 10-15 Volts DC across Make sure it is not exposed to pins 2 and 4 (Black and Red).
- Page 12 Check System Light On pH Probe Error / ORP Probe Error Verify that the pH probe and ORP Inspect the probe connections to probe are plugged in to the ensure that the connectors are clean. correct terminals. Step E Step F The pH probe plugs into the top terminal and If the connectors are clean replace the probe that the ORP probe plugs into the bottom...
- Page 13 Check System Light On pH Low The factory setting (non-adjustable) for pH Low Is a pH level of 6.9 or less. If a CO tank or Stenner pump is being used for pH Test the water to verify the pH reduction check the injection point.
- Page 14 Check System Light On pH Low The factory setting (non-adjustable) for pH Low Is a pH level of 6.9 or less. Recalibrate the probe under the ‘pH Clean the pH probe and run system Calibration Wizard’. for 120 minutes. Step J Step K If attached to a ProLogic follow instructions on page 5.
- Page 15 Check System Light On pH Low The factory setting (non-adjustable) for pH Low Is a pH level of 6.9 or less. For AQL-CHEM2 only: If a CO tank or Stenner pump is being used, turn pump With the pump off, make sure CO off and check pH reduction circuit for 120 or 240VAC.
- Page 16 Check System Light On pH High The factory setting (non-adjustable) for pH High is a pH level of 8.1 or higher. Test the water to verify the pH Remove the probes, close the valves and value of the water. clean the flow cell with dish soap. Step O Step N It is important to test the pH value of...
- Page 17 Check System Light On pH High The factory setting (non-adjustable) for pH High is a pH level of 8.1 or higher. If a CO tank or Stenner pump is being used for pH reduction, check tank to make sure it is not depleted, clogged or turned off. Step P If tank is depleted, refill or replace the canister.
- Page 18 Check System Light On pH High The factory setting (non-adjustable) for pH High is a pH level of 8.1 or higher. Check the chemistry in the pool with emphasis on the free chlorine If CYA is under 60ppm. and the Cyanuric Acid levels. Step Q Chlorine production.
- Page 19 Check System Light On pH High The factory setting (non-adjustable) for pH High is a pH level of 8.1 or higher. Clean and the pH probe and run Recalibrate the probe under the ‘pH system for 120 minutes. Calibration Wizard’. Step R Step S If attached to a ProLogic follow instructions on page...
- Page 20 Check System Light On pH Timeout – Chk Feedr Test the water to verify the pH Remove the probes, close the valves and value of the water. clean the flow cell with dish soap. Step T Step V It is important to test the pH value of It is important to keep the probe tips wet at all the water in the flow cell as well as the times when removing the probes.
- Page 21 Check System Light On pH Timeout – Chk Feedr The factory setting (non-adjustable) for pH High is a pH level of 8.1 or higher. If a CO tank or Stenner pump is being used for pH reduction, check tank to make sure it is not depleted, clogged or turned off.
- Page 22 Check System Light On pH Timeout – Chk Feedr The pH Timeout error will occur when the pH set point has not been achieved within the time frame specified. Clean and the pH probe and run the Extend the pH feed timeout and reset ‘pH system for 120 minutes.
- Page 23 Check System Light On pH Calibration Error Note: This error occurs when the pH probe reads more than 1.0 ± the calibrated value. Recalibrate the probe under the ‘pH Clean the pH probe and run system Calibration Wizard’. for 120 minutes. Step Y Step Z If attached to a ProLogic follow instructions on page 5.
- Page 24 Check System Light On ORP Low – Chk Chlor. Note: ORP Low will be displayed if an ORP level of 350mV or less is detected. Check the free chlorine level in Verify whether or not a chlorine reducer is the pool (1.0 - 3.0ppm). being added to the pool.
- Page 25 Check System Light On ORP Low – Chk Chlor. Note: ORP Low will be displayed if an ORP level of 350mV or less is detected. Remove the probes, close the valves and Clean and the ORP probe and run clean the flow cell with dish soap. system for 120 minutes.
- Page 26 Check System Light On ORP High – Chk Chlor. / Chlor. Off Note: ORP High will be displayed if an ORP level of 950mV or greater is detected. Measure the chlorine levels using a Remove the probes, close the valves and third-party test kit.
- Page 27 Check System Light On ORP High – Chk Chlor. / Chlor. Off Note: ORP High will be displayed if an ORP level of 950mV or greater is detected. Clean and the ORP probe and run system for 120 minutes. Step AH Follow the steps on page 4.
- Page 28 Check System Light On ORP Timeout – Chlor. Off ORP Timeout will be displayed if the unit has been chlorinating for more than the selected sanitizer timeout setting without reaching the desired level. The chlorinator has been turned off. Increase the amount of time for ORP Measure the chlorine levels using a Timeout (Chemistry Extend is default) third-party test kit.
- Page 29 Check System Light On ORP Timeout – Chlor. Off ORP Timeout will be displayed if the unit has been chlorinating for more than the selected sanitizer timeout setting without reaching the desired level. The chlorinator has been turned off. Compare the pool size, cell Clean and the ORP probe and size and filter run times.
-
Page 30: Check System: Csm Comm Error
Check System: CSM Comm Error Troubleshooting Chart Inspect CSM CSM Comm Verify CSM (chem. sensing Measure 10-15VDC cable is Error module) cable between pins 2-4 plugged in (Page 8-9) for damage (black and red) (Page 8) (Page 8) (Page 9) another comm Is the CSM... -
Page 31: Check System: 'Ph Low
Check System: pH Low Troubleshooting Chart Turn pump off Test the pH of pH Low check pH Add soda ash water pool and reduction circuit to raise pH flow cell. (Page 11-13) for 120/240VAC (Page 11) (Page 11) (Page 13) Stuck solenoid Replace valve or... -
Page 32: Check System: 'Ph High
Check System: pH High Troubleshooting Chart Verify CO tank Test the pH of pH High Add muriatic or Stenner pump water pool and acid to lower pH is not depleted flow cell. (Page 14-17) (Page 14) (Page 14) (Page 15) Balance water chemistry + Refill or... - Page 33 Check System: pH Timeout Troubleshooting Chart Verify CO2 tank Test the pH of pH Timeout or Stenner pump Add muriatic water pool and is not depleted acid to lower pH flow cell. (Page 18-20) Check dispense (Page 18) (Page 18) (Page 19) Extend pH feed (Page 20)
- Page 34 Check System: ORP Low Troubleshooting Chart Check the free Identify if a ORP Low - chlorine level in chlorine reducer Suspend use Check Chlor. the pool has been used of chlorine (Page 22-23) reducer (Page 22) (Page 22) Clean flow Chlorine cell with dish reducer added?
- Page 35 Check System: ORP High Troubleshooting Chart Test the free Lower ORP set ORP High chlorine level of the point or time flow cell and pool. percentage (Page 24-25) (Page 24) (Page 24) Levels are high Clean flow in flow cell and Clean pH probe cell with dish Check...
- Page 36 Check System: ORP Timeout Troubleshooting Chart Put the system in Test water Reset ORP Timeout ‘Timed Percentage’ chemistry and Timeout Error and Super balance water. (Page 7) Chlorinate’ for 24hrs. (Page 26-27) (Page 26) (Page 26) Increase ORP Are chlorine Chlorine levels Timeout and enable levels still...
