Hayward OmniHub Installation Manual

Pool automation control
Hide thumbs Also See for OmniHub:
Table of Contents

Advertisement

Quick Links

OmniHub
Pool Automation Control
Installation Manual
Hayward Pool Products
620 Division Street, Elizabeth NJ 07207
Phone (908)-355-7995
www.hayward.com
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Contents
Before you Begin.....................3
Mounting...............................8
Plumbing..............................10
Wiring...................................11
Startup................................23
Configuration........................24
HLOMNIHUB
092711 RevA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OmniHub and is the answer not in the manual?

Questions and answers

Related Manuals for Hayward OmniHub

Summary of Contents for Hayward OmniHub

  • Page 1 092711 RevA OmniHub Pool Automation Control Installation Manual Contents Before you Begin.....3 Mounting.......8 Plumbing......10 Wiring........11 Startup........23 Configuration......24 HLOMNIHUB Hayward Pool Products 620 Division Street, Elizabeth NJ 07207 Phone (908)-355-7995 www.hayward.com USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 2 (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Hayward could void the user’s authority to operate this equipment.

  • Page 3: Table Of Contents

    Control Pad......................8 Smart Relay......................9 Temperature Sensors..................10 Plumbing........................10 Electrical Wiring High Voltage....................12 Low Voltage....................18 System Startup......................23 Configuration Pre-Programmed Configuration................26 Typical Configuration..................27 Advanced Configuration..................29 Quick Edit......................47 Control Pad Mounting Template.................57 USE ONLY HAYWARD GENUINE REPLACEMENT PARTS USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 4: Before You Begin

    115 VAC pump and Smart Relay applications • Input Power Wiring harness and miscellaneous installation hardware Note that your OmniHub may have been packaged with additional equipment and may contain spe- cific installation information on a separate Quick Start guide. What’s NOT Included...

  • Page 5: Overview

    * If a non-Hayward brand VSP or an older non-supported Hayward VSP will be used, the pump can only operate at one speed. The pump must be locally programmed to run 24 hrs/day at a fixed speed and the OmniHub will turn it on and off based on the desired programmed time.
  • Page 6 Equipment Wiring Hub All incoming/outgoing wiring will be connected to the Wiring Hub. The OmniHub can be powered by either 230 VAC or 115 VAC. Input power should be constant, not from a timer. If a timer must be used, set the timer to power the Wiring Hub continuously. For convenience, 6 ft Wiring Whips with red, white, black and green colored 12AWG wires are included with the OmniHub.
  • Page 7 Ethernet to Relay 1 (15’) Router Input Power to Smart Relay 1 To Solar Heater Filter Valve Heat pumps require Actuator input power directly Variable from electrical panel Speed Pump Diagram 2 FROM POOL POOL USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 8 OmniHub. The OmniHub is designed to be mounted outdoors at the pool pad. Both the Wiring Hub and the Control Pad are water resistant and can be left out for the winter. Details on each installation step are shown below: 1.

  • Page 9: Mounting

    57. Tighten until the bottom of the screw heads are 1/8" off the mounting surface. Position the Control Pad cutouts over the screw and slide the unit downward. You may have to tighten or loosen the screws slightly to fully engage the screw heads to get a snug fit. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 10: Smart Relay

    Refer to page 17 for Smart Relay LED information. Mount the Smart Relay to a wall or other flat surface using the mounting holes which are designed to accommodate #8 screws. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 11: Plumbing

    This will ensure that the OmniHub will detect a leak if it occurs anywhere at the pool pad. Understand that if a leak occurs after the flow switch (downstream), the OmniHub will not sense a no-flow condition.

  • Page 12: Wiring

    (see page 23) to seal this exit. Temperature Sensors, External Input & Heater Smart Relays, Variable Speed Pumps, Sense & Dispense, Aqua Rite Control Pad Communication Valve Actuators Flow Switch Low Voltage Channel Input Power Ground Screw USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 13: High Voltage

    OmniHub. Because the OmniHub must also be powered continu- ously, it may be most convenient to wire the VSP and OmniHub in parallel, on the same circuit. If this is the case, they must both be powered by the same voltage. An example of this is shown below.
  • Page 14 Single speed pumps require the use of Smart Relay(s). High voltage connections are made directly to Smart Relays which are turned on and off through a low voltage communication connection to the OmniHub. Like the OmniHub, Smart Relays can be powered by either 115 VAC or 230 VAC. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 15 The example below shows a typical retrofit of the OmniHub into a system with an existing 115 VAC filter pump. In this case, switched or timed input power to the pump is disconnected and distributed to the input sides of both the OmniHub and a Smart Relay. Because the OmniHub and Smart Relays require constant power, an existing timeclock or switch must be set to power both constantly.
  • Page 16 230 VAC to Smart Relay Relay Line 2 in Input Line 1 out Wiring Line 1 in Line 2 out Connect exist- ing pump to 230 VAC output side of Smart Relay Smart Relay USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 17 Smart Relays can be installed into an existing electrical box with a minimum volume of 16.2 in with the box supplied with the OmniHub. Use the included Wiring Whip if the supplied electrical box will be mounted within 6 ft of the power source. Red, black and green conductors are included for 230 VAC wiring.
  • Page 18 User attempted to use the On/Off button manually Green 3 fast Off or Green while the Smart Relay is being automatically controlled blinks by Wiring Hub (not allowed) Blinking Blinking Firmware upgrade in progress USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 19: Low Voltage

    Hayward Variable Speed Pump (VSP) Wiring If using a Hayward Tristar 950, Tristar 900, Super Pump 700 or MaxFlo 500, the pump can be fully controlled (schedules and speeds) by the OmniHub. Refer to the diagrams below for low voltage communication wiring instructions.
  • Page 20 Smart Relay Connection Valve Actuators The OmniHub can control up to two valve actuators which allow automated control of pool/spa, water features, cleaners or solar heating and is compatible with standard valve actuators manufactured by Hayward, Pentair/Compool, and Jandy. Actuators have 15 ft cables that are terminated with connec- tors that plug directly into the Hub as shown on page 11.
  • Page 21 Connect the external switch as shown below. After properly configuring the OmniHub (see Configuration Wizard), the filter pump and/or desired pool equipment will be forced on or off when the external device is activated.
  • Page 22 “snaps” into place in order to provide a reliable connection. Optional Sense and Dispense The OmniHub can be used with the Hayward HL-CHEM Sense and Dispense Kit. Using the HL- CHEM, the OmniHub will continuously monitor the pool's pH/ORP levels and automatically dispense chemicals (using a Hayward Aqua Rite salt chlorinator or a liquid/tablet feeder) to correct pH or add chlorine when needed.
  • Page 23 Connection to the web is optional. If web enabled devices such as PCs, laptops, tablets or phones will be used to access the OmniHub, an Ethernet or wireless connection must be made to the home router. For wireless connections, refer to the Configuration section of this manual. For Ethernet connections, use outdoor rated Cat5e or Cat6 Ethernet cable.

  • Page 24: Startup

    System Startup After confirming that all wiring has been performed according to NEC and local codes and that the Wiring Hub is properly grounded, apply power to the OmniHub. The OmniHub will take about 30 seconds to fully start. Firmware Upgrade The OmniHub's firmware is the basic operating system that runs the system.

  • Page 25: Configuration

    Configuration Initial Configuration Because this is the first time that the OmniHub has been powered on, you will be brought directly to the initial configuration screen shown below. Note that the OmniHub Control Pad uses a resistive touch screen that is appropriate for a pool environment. It requires a deliberate push when selecting a button.
  • Page 26 Load Existing Configuration This option should be used if you already have a pre-made configuration loaded onto a thumb drive that is ready to be uploaded to the OmniHub. Navigation The Configuration Wizard has been designed to be intuitive allowing most users the ability to navi- gate with little instruction.
  • Page 27 Network Diagnostic screen will appear and the OmniHub will run through a series of checks to verify connection to the access point. When the system is done running through the diagnostics, press the check mark to continue to the next section of the Configuration Wizard.

  • Page 28: Typical Configuration

    When registering the OmniHub and creating a web account, you’ll be prompted to enter a Time Zone. Be sure to enter the same time zone as the physical location of the OmniHub, otherwise schedules and timers will be inaccurate.k (AM/PM) or 24hr clock (military time). Save by touching...
  • Page 29 Configuration Summary - The Configuration Summary screen appears once you reach the end of the Configuration Wizard. This screen details all of the equipment that you have connected and configured to your OmniHub. Verify that the information on this screen is correct and then press the check mark to continue.

  • Page 30: Advanced Configuration

    Select the number and advance. You’ll be brought to a screen where you can add, delete or edit a Body of Water. When initially configuring the OmniHub, a “?” will appear in the Body of Water button. You will have to configure this body of water by selecting it and then touching the Advance button.
  • Page 31 Name Filter Pump - Touch the box and use the keyboard to name the filter pump. What Type of Pump? - Depending on your answer, the OmniHub will use one Smart Relay (single speed pumps), two Smart Relays (two speed pumps) or the low speed communication bus (Hayward supported VSP pumps only) for pump control.
  • Page 32 Flow Monitoring Enabled? Requires use of a Hayward flow switch. This feature will help protect the filter pump from damage due to no flow. When Yes is selected, the OmniHub will monitor the state of water flow when the filter pump is on. If no flow is detected for more than 15 minutes, the OmniHub will shut down the pool pump and will indicate an error.
  • Page 33 How Many Heaters? - Answer "0", "1" or "2" to this question. The OmniHub supports up to two heaters for one body of water (conventional and solar only) and only one heater for two bodies of water.
  • Page 34 Does the Solar Heater Have a Pump? Select whether the solar heating sys- tem has a dedicated recirculation pump. If so, the OmniHub will turn this pump on when the pool temperature is below the heater setting and there is solar heat available.
  • Page 35 Set a speed that will ensure that there will be sufficient flow for the solar heating system to operate properly. Do you have a Sense & Dispense Module? Select Yes if a Hayward HL-CHEM (sold separately) is connected to the OmniHub.
  • Page 36 The OmniHub will continuously measure ORP and generate/ dispense the proper amount of chlorine to maintain this setpoint. ORP Timeout - Select a timeout interval. If the OmniHub has been chlorinating for more than the selected ORP timeout without reaching the desired level, the chlorinator will turn off and display an alarm.
  • Page 37 How many cleaners? The OmniHub has two actuator outputs. If controlling a pool and spa (two bodies of water), you cannot add a cleaner that requires a valve.
  • Page 38 If VSP is selected: Which Hayward Unique Address? If using a VSP for your cleaner pump, you’ll be asked what is the Hayward Unique Address (HUA). If a value is already shown in the box, advance to the next screen. If no value is shown, selecting the box will bring you to a table show- ing all detected devices.
  • Page 39 Name of Water Feature - Touch the box and use the keyboard to name the water feature. Does Water feature Have a Pump? Select whether the water feature has a dedicated pump. If so, the OmniHub will turn this pump on when the water feature is scheduled to run.
  • Page 40 Do You Want to Configure Any Lights? Select yes if you are using any type of lights. The options are UCL (14V), CL4.0 (115V), CL2.5 (14V), Incandescent, and Other. Note that the OmniHub can only support ColorLogic lights in Standalone mode using its high voltage relays.
  • Page 41 Name of Accessory - Touch the box and use the keyboard to name the accessory. Does Accessory Have a Pump? Select whether the accessory has a dedicated pump. If so, the OmniHub will turn this pump on when the accessory is scheduled to run. If Yes is selected: What Type? Select the type of pump used.
  • Page 42 If freeze protection is en- abled AND the air temperature falls below the freeze threshold (refer to pump configura- tion), the OmniHub will turn on the accessory pump to circulate the water. If Yes is selected: Freeze Protect Speed? This is the speed of the pump while freeze protection is active.
  • Page 43 (typically SENS1) and touch the Done button. The sensor connection should now be shown in the box and you can advance to the next screen to continue configuration. Do You Have a Flow Switch? Select whether there is a flow switch wired to the OmniHub. If Yes is selected: Where is the Sensor Wired? Touching the box will bring you to a table showing all detected sensors connections.
  • Page 44 NOTE: Do not use the OmniHub to control fire pits or any other fire related equip- ment. Would You Like to Add an Interlock? An interlock will allow the OmniHub to turn on or to turn off a piece of pool equipment (slave) based on the state of other pool equipment (master). An example of this is would be the desire to turn on walkway lighting (slave) every time the pool deck lights (master) are turned on.
  • Page 45 If the Flow Switch detects flow, the Equipment is forced off - The Equip- ment is always off as long as the Flow Switch detects flow. Once the Flow Switch detects no flow, the Equipment will turn on. The Equipment cannot be USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 46 Pressing either button will bring you to another screen with all of the possible equipment that can be interlocked. Choose the desired external input and equipment then press save to lock in those values. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 47 Pressing any of these buttons will bring you to another screen with all of the possible equipment that can be inter- locked. Choose the desired temperature sensor, temperature and equipment then press save to lock in those values. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...

  • Page 48: Quick Edit

    Verify that the interlock statement correctly states the interlock that you would like to create and then press save to create the interlock. Configuration Summary The OmniHub displays all configured equipment in a table for you to view. Scroll through all configured devices and make sure they've been properly assigned.
  • Page 49 Type - Change the type of Filter Pump that is configured (Single Speed, 2-Speed, or VSP) HUA - Match the HUA (Hayward Unique Address) to the configured Filter Pump. This option only appears if the Filter Pump is configured as a variable speed pump.
  • Page 50 Cooldown - This feature ensures that the heater cools down before water cir- culation is stopped. When enabled, the OmniHub will continue to run the filter pump for 5 minutes after the heater turns off.
  • Page 51 Dispenser Relay or Valve - Depending on your dispenser type, select the output that controls the dispenser. ORP Timeout - Choose the ORP timeout time and desired ORP setpoint. This option is only available if ORP controls chlorination. USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 52 2-Speed or VSP. Delete a Cleaner - From this screen, if you wish to delete a cleaner that is currently configured, select the Delete button on the right of the name of the cleaner that you USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 53 Select Group of Lights - Once you select a group of ColorLogic Standalone Lights, all of the options for those lights will appear on the next screen. These options are USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 54 Delete an Accessory - From this screen, if you wish to delete an accessory that is currently configured, select the Delete button on the right of the name of the acces- USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 55 These steps are described in the Configuration Guide portion of this manual. Select an Interlock - Selecting an interlock from this screen will allow you to view that in- USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 56 Not Now - Skip network setup and continue with Configuration Wizard. Mood Color - To alert the user of warning conditions (no flow, failed sensor, etc.), the OmniHub can change its screen color. The screen can display yellow or red depending on the severity of the condition.
  • Page 57 USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 58 USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
  • Page 59 Aqua Plus and SwimPure chlorination products to be free of defects in materials and workmanship, under normal use and service, for a period of three (3) years. Hayward also warrants its Aqua Trol chlorination products to be free of defects in materials and workmanship, under normal use and service for a period of one (1) year.
  • Page 60 Hayward is a registered trademark and OmniHub is a trademark of Hayward Industries, Inc. © 2018 Hayward Industries, Inc. All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties.
