Pro Logic
Automation and Chlorination
Operation Manual
for models
PL-PS-4
PL-PS-8-V
PL-PS-8
PL-PS-16-V
PL-PS-16
www.haywardnet.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro Logic and is the answer not in the manual?

Questions and answers

Related Manuals for Hayward Pro Logic

Summary of Contents for Hayward Pro Logic

  • Page 1 Add calcium to increase. Drain and add water to decrease. Operation Manual Electrolytic Cell inspect & clean Refer to section in manual. for models PL-PS-4 PL-PS-8-V PL-PS-8 PL-PS-16-V PL-PS-16 620 Division St. 092331D RevF www.haywardnet.com Elizabeth, NJ 07207 Copyright © 2010 Hayward...

  • Page 2: Important Safety Instructions

    (3) years. Hayward/Goldline also warrants its Aqua Trol chlorination products to be free of defects in materials and work- manship, under normal use and service for a period of one (1) year. These warranties are applicable from the initial date of installation on private residential swimming pools in the US and Canada.

  • Page 3: Table Of Contents

    How to Add or Remove Salt..........36 System Maintenance Servicing and Cleaning the Chlorinator Cell....... 39 Winterizing................39 Spring Startup................ 39 Troubleshooting & Service Mode ............... 40 Diagnostic Information Check System Indicator............40 Diagnostic Menu..............42 Warranty Pro Logic Warranty..............48...

  • Page 4: Automation

    The Hayward Pro Logic is a multifunction pool controller used to fully manage your pool/spa system. The Pro Logic can control pumps, valves, lighting, heaters, and chlorination. Although the Pro Logic is easy to use, it is important to completely read through this operating manual before attempting to operate the control.

  • Page 5: Chlorination

    Default Display Turn power on at the main panel and turn the Pro Logic control power circuit breaker on. The keypad will show the default display. The default display alternates between the day/time, air and pool (or spa) temperature, pool/ spa sanitizer setting, and salt level.

  • Page 6: Output Names

    While the main objective of the Pro Logic is to automate the operation of your pool/spa system, there may be Pro Logic main unit.

  • Page 7: Lights And Aux Outputs

    ColorLogic Relay: This selection will only appear if an optional ColorLogic Network Module (AQL-COLOR- MODHV) is detected at startup. The Network Module allows the Pro Logic to control custom colors and light shows in Hayward Generation 4 or later ColorLogic pool and spa lights. Refer to the AQL-COLOR-MODHV manual for details on how to configure an Aux output for use with these lights.

  • Page 8: Pool/Spa Valves

    If the current (amps) display is 0.00A, then the chlorinator is operating normally but is in the off part illuminated and the Pro Logic will remain in this mode of operation until manually taken out of service mode. of its normal operating cycle. Simply press either the “+” or “-“ key to start a new cycle.

  • Page 9: Using The Programming Buttons

    • Pool Filter VSP Err: x -- If variable speed is selected for the Pool Filter and the Hayward VSP is indicating and error. x is the same decimal error displayed by the VSP itself.

  • Page 10: Programming Menu Flowchart

    3 months and clean the cell if necessary. The Pro Logic will automatically remind you when it is time and spa sensor display “Inspect Cell, + to reset” as part of the rotating Default Menu. Clean the cell and then press the “+”...

  • Page 11: Settings Menu

    System Maintenance The Pro Logic’s six main menus have many items in each that allow you to customize the operation of your pool/ spa equipment. The chart on the previous page shows the Pro Logic’s six menus as well as each menu’s specific settings.
  • Page 12 Spa Heater2 Adjust the desired priority interval (Never, 1hr, 2hrs, 3hrs ...22hrs, 23hrs, Always) Priority: 10 hours Move to previous/next menu item The spa heater priority setting will only appear if the system has been setup for “spa only” or “pool and spa”and if priority has been enabled for Spa Heater2.
  • Page 13 Pro Logic Super Chlorinate function. The Pro Logic will turn on the filter pump, set the pool/spa valves to the correct position, and set the chlorine generator to maximum output. The superchlorinate function will continue for the programmed number of hours (see Timers/Super Chlorinate Hours) overriding the normal filter pump timeclock settings.

  • Page 14: Type Of Salt

    Move to previous/next menu item chlorine production. A high salt level can cause the Pro Logic to stop chlorinating. The salt in your pool/spa is When “Enabled”, the keypad will beep every time a key is pressed. If this audible indication is not constantly recycled and the loss of salt throughout the swimming season should be minimal.

  • Page 15: Timers Menu

    General Water Chemistry Confirm Change: Push to confirm the channel change Salt is required only if you are using the chlorinator features on the Pro Logic Control. If you are NOT using the + to proceed Move to previous/next menu item chlorinator, it is recommended that you follow all of the other chemistry recommendations besides salt.

  • Page 16: Start/Stop Superchlorination

    This menu is only available if the system has been setup for “pool and spa-std”. During the programmed prevent the relay/valve from operating—see a more detailed discussion under Automatic Sys- spa time, the Pro Logic will move the pool/spa valves into the “spa-only” position and turn on the tem Operation/Timers Menu/Aux Timeclock or in Troubleshooting/Diagnostic Information.

  • Page 17: Set The Heater Temperature

    Pro Logic will keep the relay off until these other conditions are suitable for operation. If the Aux1 relay is on during the programmed off time, it may be because of freeze protection.

  • Page 18: Group Function

    Group Function Clean Probe Wizard Push to access Clean Probe Wizard The Pro Logic offers the ability to assign a Group function to a particular button. Instead of a button controlling one + to enter Move to previous/next menu item particular function, the button can be programmed to initiate a sequence of commands that are programmed in the Configuration Menu.
  • Page 19 “Remote Menus” is to use the local display/keypad. Note that all functions in the table may not be offered. The available functions are dependent on how the Pro Logic is configured. For example, if the Pro Logic is configured for a single heater, “Heater2” will not be available as an...

  • Page 20: Configuration Menu

    See valve3 Group section for operation information for the Group function. Super Chlorinate The Pro Logic can be programmed to Super Chlorinate the pool or spa while running a group command. When the Super Chlorinate – The Super Chlorinate function can be assigned to any Aux, Lights or Valve Group starts, the Super Chlorinate cycle will begin.
  • Page 21 Pool/Spa Setup the timeclocks. A sheet of small name labels is included with the Pro Logic main unit and each remote If “Pool Only” or “Spa Only” are selected, then the pool/spa valves are not needed and pushing the display/keypad so that the “Valve3”...
  • Page 22 Filter Name The Pro Logic allows you to assign any one of a number of names (e.g. “Filter Pump, Pool Filter, Spa Filter, etc.) to the filter relay. This will make the Pro Logic more user friendly to the homeowner when they want to control the filter equipment.
  • Page 23 It is important to flow switch, the Pro Logic monitors the state of water flow when the filter pump is on. If no flow is note that “Solar”...
  • Page 24 AIR temperature sensor falls below the freeze threshold (selectable in low speed, group and ph dispense Filter Configuration Menu - page 20), the Pro Logic will turn on the spa filter pump to circulate the Toggle between Enabled...
  • Page 25 2-speed filter pump is selected Toggle between Enabled and Disabled (default) Allow Low Speed Low Speed of a 2-Speed Spa Filter Pump – the Pro Logic will turn on the lights relay whenever the low Disabled Move to next menu item or previous/next configuration menu speed operation of the Dual Equipment Spa filter pump is required.
  • Page 26 This provides the most cost effective way of lights on or off. A sheet of small name labels is included with the Pro Logic main unit and each remote heating the pool. When solar heat is not available, the conventional heater will operate normally.
