Hayward ColorLogic WFBCUS1100 Owner's Manual page 5

Exploded View
8. Retaining
Ring
7. Lens
Accent Light
(included with
WFBCUS1100)
2. Housing
1.5" SCHED
40 Electrical
Conduit (Not
Included)
**Plaster Ring only adjustable during Installation.
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
11. Nozzle Nut
14. O-Ring
9-10. Adjustable
Nozzle (1/2" or
3/4")
6. Plaster Ring**
1. Cardboard Spacer
1.5" SCHED 40
PVC Pipe (Not
Included)
4
