7.4 Hole-punching Prohibited Areas
Punched holes in the shaded areas may cause errors.
For job separation sheet requirements, refer to
Reference Point
HINT
"7.7 Job Separation Sheet" on page 169
35
Front Side
Center line
If there are any holes in the 35mm wide central column, you can set the doc-
ument a bit to the left or right to avoid detecting error.
7.4 Hole-punching Prohibited Areas
.
Unit : mm
Leading edge
Bottom edge
7
165
