Fujitsu fi-5950 Operator's Manual page 126

11. Clean the Feed rollers (metal rollers, each set consists of 2 rollers, 9
locations) on the upper side of the lower transport path using a lint-free
cloth moistened with the cleaner F1.
Take care especially to remove black stains on the rollers, since such stains are deteriorating the
feeding performance.
12. Clean the Pinch rollers (rubber rollers, each set consists of 2 rollers, 9
locations) on the upper side of the upper transport path using a lint-free
cloth moistened with the cleaner F1.
13. Close the ADF cover.
For details, refer to
If all the cleaning is done, reset the Cleaning counter by referring
the Consumable/Cleaning Counter" on page
Pinch roller
"2.3 Opening and Closing ADF" on page
123.
4.4 Cleaning the Rollers (with a lint-free cloth)
Feed rollers
12.
"5.2 How to check and reset
4
115
