2.4 Opening and Closing Top Cover
Under the Top cover, there are a storage tray for storing the consumables and cleaning goods and a space
for installing the Post-Imprinter. When you use the tray or access the Post-Imprinter, open the top cover as
follows.
■ Opening the Top Cover
Press the tabs of the Top cover and open the top cover.
Tab
■ Closing the Top cover
Close the Top cover and press lightly until it is fixed with the tab.
14
2.4 Opening and Closing Top Cover
Top cover
Top cover
Storage tray
Space for installing the Post-Imprinter
