Scanning Documents Longer Than A3 - Fujitsu fi-5950 Operator's Manual

3.2 Scanning Documents Longer than
A3
When scanning documents longer than A3, set the feeding option to "Long Page".
This scanner can scan documents up to 3,048mm (120inch) long.
Below is the procedure with TWAIN driver.
1. Set the document on the hopper.
Refer to section
2. Adjust stacker in accordance with document size.
Refer to section
HINT
3. Start TWAIN driver with the application used.
Refer to section
70

3.2 Scanning Documents Longer than A3

"2.6 Loading Documents on the Hopper" on page
"2.7 Setting up the Stacker" on page
When scanning long pages (longer than A3), the document may be longer
than the stacker extension even if it's pulled to the outermost position. In
case like this, place a thick paper about the size of A4 on the stopper and
make a slope as depicted below.
Stopper
Stacker Extension
"2.10 Scanning Documents" on page
17.
22.
Thick Paper
30.
