given for the same model transducer, refer to paperwork supplied
with transducer to determine impedance.

StructureScan

This feature is automatically enabled when a TotalScan transducer is
plugged in before the unit has been powered on.
Autopilot setup
Verifying the autopilot connection
When an AC12N, AC42N, NAC-1 or SG05 autopilot computer is
connected to the unit, the system automatically detects the
autopilot and an Autopilot menu icon is included in the Settings
menu.
If no Autopilot icon is available in the menu, establish the
connection by running the auto select process.
If the autopilot computer is turned off independently of the unit,
the Autopilot menu icon remains available, but only a few of the
menu items are available.
Commissioning the autopilot
Note:
Ú A dedicated physical STBY key is required for
commissioning. This can be on the autopilot control head,
on an autopilot remote controller or the NAC-1 standby
button.
When the autopilot installation is completed, the commissioning
procedures must be performed. Failure in setting up the autopilot
correctly may prohibit the autopilot from functioning properly.
The setup of the autopilot computers can be done in full from the
unit or from a separate autopilot control head.
The following sections describe how you configure the autopilot
from the unit. If you connect the unit to an already commissioned
autopilot system, you only have to do an automatic source selection
as described above before the autopilot is ready to be used.
