4

Wiring

Guidelines
Don't do this:
Don't make sharp bends in the
cables.
Don't run cables in a way that
allows water to flow down into
the connectors.
Don't route the data cables in
areas adjacent to radar,
transmitter, or large current
carrying cables.
Warning:
Before starting the installation, be sure to
turn electrical power off. If power is left on or turned on
during the installation, fire, electrical shock, or other
serious injury may occur. Be sure that the voltage of the
power supply is compatible with the unit.
Warning:
The unit has a voltage rating of 12 V DC, it
is not suited for use with 24 V DC systems.
Warning:
The positive supply wire (red) should
always be connected to (+) DC with the supplied fuse
or a circuit breaker (closest available to fuse rating).
Wiring | GO XSE Installation Manual
Do this:
Do make drip and service loops.
Do cable-tie all cables to keep
them secure.
Do solder/crimp and insulate all
wiring connections, if extending
or shortening power, or NMEA
2000 cables.
Do leave room adjacent to
connectors to ease plugging
and unplugging of cables.
21
